Eaton xEffect xEffect - FAZ-T Miniature Circuit Breaker, 1-Pole, 32 A, Type B, 240 V ac AC, 60 V DC, 10 kA Breaking
- RS Stock No.:
- 129-396
- Mfr. Part No.:
- 142509 FAZT-B32/1N
- Brand:
- Eaton
Subtotal (1 unit)*
£76.55
(exc. VAT)
£91.86
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £76.55 |
*price indicative
- RS Stock No.:
- 129-396
- Mfr. Part No.:
- 142509 FAZT-B32/1N
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 1 | |
| Current Rating | 32 A | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 240 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 10kA | |
| Range | xEffect | |
| Series | xEffect - FAZ-T | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Width | 36 mm | |
| Height | 75.5mm | |
| Depth | 70.5mm | |
| Standards/Approvals | IEC/EN 60947-2 EN45545-2 IEC 61373 | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 1 | ||
Current Rating 32 A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 240 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 10kA | ||
Range xEffect | ||
Series xEffect - FAZ-T | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Width 36 mm | ||
Height 75.5mm | ||
Depth 70.5mm | ||
Standards/Approvals IEC/EN 60947-2 EN45545-2 IEC 61373 | ||
- COO (Country of Origin):
- RO
The Eaton 32A, single-pole plus neutral miniature circuit breaker (MCB) with a B characteristic is designed as switchgear for industrial and advanced commercial applications.
Degree of protection IP20
RoHS compliant
