INA PAB40-PP-AS Bearing with 40 mm ID 62 mm OD 600 kN
- RS Stock No.:
- 172-1097
- Mfr. Part No.:
- PAB40-PP-AS
- Brand:
- INA
Bulk discount available
Subtotal (1 unit)*
£104.85
(exc. VAT)
£125.82
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £104.85 |
| 5 - 9 | £100.66 |
| 10 + | £98.56 |
*price indicative
- RS Stock No.:
- 172-1097
- Mfr. Part No.:
- PAB40-PP-AS
- Brand:
- INA
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | INA | |
| Product Type | Bearing | |
| Outside Diameter | 62mm | |
| Length | 80mm | |
| Inside Diameter | 40mm | |
| End Type | Sealed | |
| Closure Type | Closed | |
| Base to Bore Centerline | 31mm | |
| Static Load Rating | 600kN | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand INA | ||
Product Type Bearing | ||
Outside Diameter 62mm | ||
Length 80mm | ||
Inside Diameter 40mm | ||
End Type Sealed | ||
Closure Type Closed | ||
Base to Bore Centerline 31mm | ||
Static Load Rating 600kN | ||
Standards/Approvals No | ||
Linear bearings and linear bearing and housing units are available in the compact, light, heavy duty, machined and plain bearing range. The bearings can support high loads while having a relatively low mass and allow the construction of linear guidance systems with unlimited travel. Each series has quite specific characteristics that makes it particularly suitable for certain applications.
Linear bearings
Compensation of misalignment
Linear bearing and housing units
Simple location
Housing designs
Highly cost-effective
Sealing
Lubrication
Operating temperature
Operating limits
Suffixes
Permaglide plain bearing range
Linear plain bearings
