Telemecanique Sensors OsiSense XC Series Roller Lever Limit Switch Body, 2 NC, IP66, IP67, Plastic Housing, 240V ac,

RS Stock No.:: 700-4185
Mfr. Part No.:: ZCP29
Brand:: Telemecanique Sensors

Telemecanique Sensors OsiSense XC Series Roller Lever Limit Switch Body, 2 NC, IP66, IP67, Plastic Housing, 240V ac,

Subtotal (1 unit)*

£22.50

(exc. VAT)

£27.00

(inc. VAT)

FREE delivery for orders over £60.00

Limited stock

Plus 43 left, shipping from 27 July 2026
Plus 18 left, shipping from 27 July 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£22.50

*price indicative

Precision Limit Switching You Can Rely On with XCMH Series

Designed for durability and precision, Telemecanique XCMH limit switches provide dependable position control in even the toughest environments. With rugged construction and versatile configurations, they ensure consistent performance and long-lasting reliability across your industrial applications.

Shop Here

RS Stock No.:: 700-4185
Mfr. Part No.:: ZCP29
Brand:: Telemecanique Sensors

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Telemecanique Sensors
	Actuator Type	Roller Lever
	Product Type	Limit Switch Body
	Contact Configuration	2 NC
	IP Rating	IP66, IP67
	Housing Material	Plastic
	Contact Type	Snap Action
	Switching Current	1.5A
	Terminal Type	Screw Clamp
	Series	OsiSense XC
	Switching AC Voltage	240V ac
	Minimum Operating Temperature	-25°C
	Switching DC Voltage	250V dc
	Maximum Operating Temperature	70°C
	Depth	30mm
	Standards/Approvals	RoHS
	Width	31mm
	Length	65mm
	Hazardous Area Certification	No
	Mounting Orientation	Side
	Mechanical Life	10000000Cycles
	Conduit Entry	20 mm

	Select all
	Brand Telemecanique Sensors
	Actuator Type Roller Lever
	Product Type Limit Switch Body
	Contact Configuration 2 NC
	IP Rating IP66, IP67
	Housing Material Plastic
	Contact Type Snap Action
	Switching Current 1.5A
	Terminal Type Screw Clamp
	Series OsiSense XC
	Switching AC Voltage 240V ac
	Minimum Operating Temperature -25°C
	Switching DC Voltage 250V dc
	Maximum Operating Temperature 70°C
	Depth 30mm
	Standards/Approvals RoHS
	Width 31mm
	Length 65mm
	Hazardous Area Certification No
	Mounting Orientation Side
	Mechanical Life 10000000Cycles
	Conduit Entry 20 mm

COO (Country of Origin):: ID

Telemecanique Sensors Osizense XC Series Limit Switch Body, IP66/IP67, Plastic Housing - ZCP29

This limit switch body provides a Compact electromechanical actuator for industrial control and position-detection tasks. It employs a roller lever actuator and is designed for side fitting within machine assemblies, offering straightforward electrical connectivity via screw-clamp terminals and a 20mm conduit entry suited to standard wiring practices.

Features and Benefits:

• Roller lever actuator delivers repeatable mechanical actuation for position sensing
• Snap-action contacts enable fast switching transitions for accurate control
• 2NC contact configuration supports normally closed safety or interlock schemes
• Rated for 250V DC switching at 1.5 A to handle low-voltage DC control circuits
• Enclosure achieves IP66 and IP67 protection for resistance to dust and immersion
• Mechanical endurance of 10,000,000 cycles minimises replacement frequency

Applications

• Suitable for end-of-travel detection on conveyor indexing systems
• Ideal for safety interlocks in packaging equipment
• Used for limit sensing on automated assembly machines
• Can be used for position feedback on hydraulic or pneumatic actuators

What Terminal arrangement is provided for field wiring?

It uses screw-clamp terminals that accept solid or stranded conductors for secure connections.

How does the enclosure cope with washdown or outdoor environments?

The housing meets IP66 and IP67 protection levels, preventing ingress of dust and allowing temporary immersion.

What operating temperature range can be expected in typical installations?

The device is specified to operate from -25°C up to 70°C for common industrial ambient conditions.

How is the unit mounted within machinery?

The design is intended for side-orientation mounting to align the roller lever with moving parts.

What contact action ensures crisp switching behaviour?

The contacts employ a snap-action mechanism to provide a Rapid changeover when actuated.
