Telemecanique Sensors OsiSense XC Series Roller Plunger Limit Switch, 1 NO/1 NC, IP66, IP67, IP68, Zinc Alloy Housing,
- RS Stock No.:
- 700-4157
- Mfr. Part No.:
- XCMD2124L1
- Brand:
- Telemecanique Sensors
Subtotal (1 unit)*
£81.31
(exc. VAT)
£97.57
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 8 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £81.31 |
*price indicative
- RS Stock No.:
- 700-4157
- Mfr. Part No.:
- XCMD2124L1
- Brand:
- Telemecanique Sensors
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Telemecanique Sensors | |
| Actuator Type | Roller Plunger | |
| Product Type | Limit Switch | |
| IP Rating | IP66, IP67, IP68 | |
| Contact Configuration | 1 NO/1 NC | |
| Housing Material | Zinc Alloy | |
| Contact Type | Snap Action | |
| Switching Current | 1.5A | |
| Terminal Type | Cable | |
| Series | OsiSense XC | |
| Minimum Operating Temperature | -25°C | |
| Switching AC Voltage | 240V ac | |
| Switching DC Voltage | 250V dc | |
| Maximum Operating Temperature | 70°C | |
| Length | 50mm | |
| Depth | 16mm | |
| Standards/Approvals | CCC, CSA, EN 60204-1, IEC 60204-1, UL | |
| Width | 30mm | |
| Hazardous Area Certification | NO | |
| Mounting Orientation | Multi Directional | |
| Operating Force | 2.5N | |
| Mechanical Life | 10000000Cycles | |
| Conduit Entry | M20 | |
| Select all | ||
|---|---|---|
Brand Telemecanique Sensors | ||
Actuator Type Roller Plunger | ||
Product Type Limit Switch | ||
IP Rating IP66, IP67, IP68 | ||
Contact Configuration 1 NO/1 NC | ||
Housing Material Zinc Alloy | ||
Contact Type Snap Action | ||
Switching Current 1.5A | ||
Terminal Type Cable | ||
Series OsiSense XC | ||
Minimum Operating Temperature -25°C | ||
Switching AC Voltage 240V ac | ||
Switching DC Voltage 250V dc | ||
Maximum Operating Temperature 70°C | ||
Length 50mm | ||
Depth 16mm | ||
Standards/Approvals CCC, CSA, EN 60204-1, IEC 60204-1, UL | ||
Width 30mm | ||
Hazardous Area Certification NO | ||
Mounting Orientation Multi Directional | ||
Operating Force 2.5N | ||
Mechanical Life 10000000Cycles | ||
Conduit Entry M20 | ||
- COO (Country of Origin):
- ID
Osiswitch miniature limit switches
40 % time-saving on electrical connection.
Fully interchangeable heads.
Pre-wired (1 metre).
Standards
EN50047
