Telemecanique Sensors XF9 Series Roller Lever Limit Switch, SPDT, IP54, Aluminium Alloy Housing, 50A
- RS Stock No.:
- 609-6899
- Mfr. Part No.:
- XF9D251
- Brand:
- Telemecanique Sensors
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 609-6899
- Mfr. Part No.:
- XF9D251
- Brand:
- Telemecanique Sensors
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Telemecanique Sensors | |
| Actuator Type | Roller Lever | |
| Product Type | Limit Switch | |
| Contact Configuration | SPDT | |
| IP Rating | IP54 | |
| Housing Material | Aluminium Alloy | |
| Contact Type | Snap Action | |
| Terminal Type | Cable | |
| Switching Current | 50A | |
| Series | XF9 | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | RoHS | |
| Width | 32mm | |
| Depth | 33mm | |
| Length | 110mm | |
| Hazardous Area Certification | No | |
| Mechanical Life | 10000000Cycles | |
| Mounting Orientation | Side | |
| Conduit Entry | 20 mm | |
| Select all | ||
|---|---|---|
Brand Telemecanique Sensors | ||
Actuator Type Roller Lever | ||
Product Type Limit Switch | ||
Contact Configuration SPDT | ||
IP Rating IP54 | ||
Housing Material Aluminium Alloy | ||
Contact Type Snap Action | ||
Terminal Type Cable | ||
Switching Current 50A | ||
Series XF9 | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals RoHS | ||
Width 32mm | ||
Depth 33mm | ||
Length 110mm | ||
Hazardous Area Certification No | ||
Mechanical Life 10000000Cycles | ||
Mounting Orientation Side | ||
Conduit Entry 20 mm | ||
- COO (Country of Origin):
- FR
Over-travel switch
Over-travel switch for power circuits, specially designed to guarantee the safety of lifting devices.
The switch is fitted with an LC1-D contactor head.
Possibility of adding auxiliary contacts (LA1-DN11).
