Telemecanique Sensors ZCKJ Series Limit Switch, 1 NO/1 NC, IP65, Metal Housing, 240V ac, 3A
- RS Stock No.:
- 360-8455
- Mfr. Part No.:
- ZCKJ1
- Brand:
- Telemecanique Sensors
Subtotal (1 unit)*
£40.91
(exc. VAT)
£49.09
(inc. VAT)
FREE delivery for orders over £60.00
Limited stock
- 120 left, ready to ship
- Plus 39 left, ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £40.91 |
*price indicative
- RS Stock No.:
- 360-8455
- Mfr. Part No.:
- ZCKJ1
- Brand:
- Telemecanique Sensors
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Telemecanique Sensors | |
| Product Type | Limit Switch | |
| Contact Configuration | 1 NO/1 NC | |
| IP Rating | IP65 | |
| Housing Material | Metal | |
| Contact Type | Snap Action | |
| Terminal Type | Screw Clamp | |
| Switching Current | 3A | |
| Series | ZCKJ | |
| Switching AC Voltage | 240V ac | |
| Switching DC Voltage | 250V dc | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 70°C | |
| Length | 77mm | |
| Width | 40mm | |
| Depth | 44mm | |
| Standards/Approvals | EN, IEC, REACH, RoHS | |
| Hazardous Area Certification | NO | |
| Conduit Entry | PG13 | |
| Select all | ||
|---|---|---|
Brand Telemecanique Sensors | ||
Product Type Limit Switch | ||
Contact Configuration 1 NO/1 NC | ||
IP Rating IP65 | ||
Housing Material Metal | ||
Contact Type Snap Action | ||
Terminal Type Screw Clamp | ||
Switching Current 3A | ||
Series ZCKJ | ||
Switching AC Voltage 240V ac | ||
Switching DC Voltage 250V dc | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 70°C | ||
Length 77mm | ||
Width 40mm | ||
Depth 44mm | ||
Standards/Approvals EN, IEC, REACH, RoHS | ||
Hazardous Area Certification NO | ||
Conduit Entry PG13 | ||
RoHS Status: Exempt
Standard Limit Switch Body / LED (ZCKJ)
Telemecanique OsiSense XCKJ series limit switch bodies allow complete limit switch assemblies to be constructed using ZCKE/Y limit switch heads and actuators.
Features and Benefits
Snap action contacts with positive opening operation
-25 to +70°C operating temperature
Protected to IP66
Robust metal body
Approvals
UL, CSA
Standards
VDE0660, IEC947-5-1
