Telemecanique Sensors ZCKJ Series Roller Lever Limit Switch, SPDT, IP66, Metal Housing, 240V ac, 3A
- RS Stock No.:
- 221-2052
- Mfr. Part No.:
- ZCKJ01
- Brand:
- Telemecanique Sensors
Subtotal (1 unit)*
£72.30
(exc. VAT)
£86.76
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 05 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £72.30 |
*price indicative
- RS Stock No.:
- 221-2052
- Mfr. Part No.:
- ZCKJ01
- Brand:
- Telemecanique Sensors
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Telemecanique Sensors | |
| Product Type | Limit Switch | |
| Actuator Type | Roller Lever | |
| Contact Configuration | SPDT | |
| IP Rating | IP66 | |
| Housing Material | Metal | |
| Contact Type | 1 CO | |
| Switching Current | 3A | |
| Terminal Type | Screw Clamp Terminal | |
| Series | ZCKJ | |
| Switching AC Voltage | 240V ac | |
| Minimum Operating Temperature | -25°C | |
| Switching DC Voltage | 250V dc | |
| Maximum Operating Temperature | 70°C | |
| Length | 80mm | |
| Depth | 44mm | |
| Width | 43mm | |
| Standards/Approvals | IEC 60255-7 Category 3, IEC 60664, IEC 60947-1 | |
| Hazardous Area Certification | NO | |
| Mechanical Life | 5000000Cycles | |
| Conduit Entry | 1 Cable Gland x PG13.5 | |
| Mounting Orientation | Side | |
| Select all | ||
|---|---|---|
Brand Telemecanique Sensors | ||
Product Type Limit Switch | ||
Actuator Type Roller Lever | ||
Contact Configuration SPDT | ||
IP Rating IP66 | ||
Housing Material Metal | ||
Contact Type 1 CO | ||
Switching Current 3A | ||
Terminal Type Screw Clamp Terminal | ||
Series ZCKJ | ||
Switching AC Voltage 240V ac | ||
Minimum Operating Temperature -25°C | ||
Switching DC Voltage 250V dc | ||
Maximum Operating Temperature 70°C | ||
Length 80mm | ||
Depth 44mm | ||
Width 43mm | ||
Standards/Approvals IEC 60255-7 Category 3, IEC 60664, IEC 60947-1 | ||
Hazardous Area Certification NO | ||
Mechanical Life 5000000Cycles | ||
Conduit Entry 1 Cable Gland x PG13.5 | ||
Mounting Orientation Side | ||
- COO (Country of Origin):
- FR
This Schneider Electric set, including one cover and one indicator light module, is part of the XCKJ limit switches range. It is a separate part for plug-in ZCKJ bodies. The indicator modules includes 2 LEDs, 24V DC.
Mercury free Yes
