Telemecanique Sensors ZCD Series Roller Lever Limit Switch, 2 NC, IP66, IP67, Zinc Alloy Housing, 240V ac, 1.5A

RS Stock No.:: 221-2051
Mfr. Part No.:: ZCD29
Brand:: Telemecanique Sensors

Telemecanique Sensors ZCD Series Roller Lever Limit Switch, 2 NC, IP66, IP67, Zinc Alloy Housing, 240V ac, 1.5A

Subtotal (1 unit)*

£34.00

(exc. VAT)

£40.80

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

1 unit(s) ready to ship
Plus 5 unit(s) shipping from 09 December 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£34.00

*price indicative

Precision Limit Switching You Can Rely On with XCMH Series

Designed for durability and precision, Telemecanique XCMH limit switches provide dependable position control in even the toughest environments. With rugged construction and versatile configurations, they ensure consistent performance and long-lasting reliability across your industrial applications.

Shop Here

RS Stock No.:: 221-2051
Mfr. Part No.:: ZCD29
Brand:: Telemecanique Sensors

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Telemecanique Sensors
	Product Type	Limit Switch
	Actuator Type	Roller Lever
	Contact Configuration	2 NC
	IP Rating	IP66, IP67
	Housing Material	Zinc Alloy
	Contact Type	Snap Action
	Terminal Type	Screw Clamp
	Switching Current	1.5A
	Series	ZCD
	Minimum Operating Temperature	-25°C
	Switching DC Voltage	250V dc
	Switching AC Voltage	240V ac
	Maximum Operating Temperature	70°C
	Depth	65mm
	Standards/Approvals	CSA C22.2 No 14, UL 508, EN/IEC 60947-5-1, IEC 60664, IEC 60947-1
	Length	30mm
	Width	31mm
	Hazardous Area Certification	No
	Conduit Entry	20 mm
	Mechanical Life	5000000Cycles
	Mounting Orientation	Side

	Select all
	Brand Telemecanique Sensors
	Product Type Limit Switch
	Actuator Type Roller Lever
	Contact Configuration 2 NC
	IP Rating IP66, IP67
	Housing Material Zinc Alloy
	Contact Type Snap Action
	Terminal Type Screw Clamp
	Switching Current 1.5A
	Series ZCD
	Minimum Operating Temperature -25°C
	Switching DC Voltage 250V dc
	Switching AC Voltage 240V ac
	Maximum Operating Temperature 70°C
	Depth 65mm
	Standards/Approvals CSA C22.2 No 14, UL 508, EN/IEC 60947-5-1, IEC 60664, IEC 60947-1
	Length 30mm
	Width 31mm
	Hazardous Area Certification No
	Conduit Entry 20 mm
	Mechanical Life 5000000Cycles
	Mounting Orientation Side

COO (Country of Origin):: ID

Telemecanique Sensors ZCD Series Limit Switch, IP66 and IP67, Zinc Alloy Housing - ZCD29

This limit switch provides position detection and circuit switching for industrial machinery using a roller lever actuator and snap-action contacts. It is intended for side-mounted installation in systems requiring weatherproof operation and Compact switching capability across a broad ambient temperature range.

Features and Benefits:

• IP66/IP67 enclosure for dust-tight and temporary immersion protection
• Zinc alloy housing offering robust mechanical protection
• 2NC contact arrangement for dual normally closed control circuits
• Snap-action contacts delivering swift switching at 1.5A
• 250V dc and 240V ac switching capability for varied power systems
• Screw-clamp terminals enabling secure conductor connections

Applications

• Suitable for conveyor end-of-travel detection in manufacturing
• Ideal for gate position sensing in outdoor installations
• Used for safety interlocks where side mounting is required
• Can be used for machine stop signalling in automation lines
• Suitable for equipment operating between -25°C and 70°C

What conduit entry is provided for cable routing?

A 20 mm conduit entry is supplied for conduit or gland attachment.

How long is the expected mechanical service before replacement?

The mechanism is rated for 5,000,000 cycles of mechanical life.

What approvals confirm compatibility with industrial electrical standards?

It meets CSA C22.2 No 14, UL 508, EN/IEC 60947-5-1, IEC 60664 and IEC 60947-1.

Which mounting orientation is recommended for reliable actuation?

The device is designed for side mounting to suit lever actuation geometry.

What Terminal type should installers expect when wiring?

The switch uses screw-clamp terminals for conductor fastening.
