Omron Short Hinge Roller Lever Limit Switch, SPDT, Metal Housing

View all Limit Switches

Subtotal (1 unit)*

£45.62

(exc. VAT)

£54.74

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 3 unit(s) shipping from 18 May 2026
  • Plus 2 unit(s) shipping from 25 May 2026
  • Plus 17 unit(s) shipping from 15 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£45.62

*price indicative

RS Stock No.:
215-7086
Mfr. Part No.:
DZ-10GW22-1B
Brand:
Omron
Find similar products by selecting one or more attributes.
Select all

Brand

Omron

Actuator Type

Short Hinge Roller Lever

Product Type

Limit Switch

Contact Configuration

SPDT

Housing Material

Metal

Contact Type

Snap Action

Terminal Type

Screw

Minimum Operating Temperature

-10°C

Maximum Operating Temperature

80°C

Width

40mm

Standards/Approvals

RoHS

Depth

40mm

Length

84mm

Hazardous Area Certification

NO

Conduit Entry

20 mm

Mounting Orientation

Side

Mechanical Life

10000000Cycles

Omron Series DZ Limit Switch, 10A Maximum Current, DPDT Pole and Throw Configuration - DZ-10GW22-1B


This limit switch is designed for precision control in various applications. Featuring a short hinge roller lever, it operates effectively across temperature ranges from -25°C to +80°C. The switch has a dual-pole, double-throw (DPDT) configuration, providing a robust solution for managing two independent circuits. This high-performance component caters specifically to the demands of industrial automation and mechanical systems, ensuring reliability and efficiency.

Features & Benefits


• Incorporates two independent switches for versatile application

• Supports a maximum current rating of 10A for reliable operation

• Designed for efficient control in circuits with different voltages

• Features a compact design for easy installation in limited spaces

Applications


• Suitable for automation systems requiring dual circuit control

• Used for precise control in machinery setups and electrical systems

• Ideal for needing temperature-resistant components

• Can be implemented in industrial environments for reliability and efficiency

How does this switch handle different voltage applications?


The design allows for the control of two independent circuits operating on separate voltages, making it suitable for multi-voltage environments.

What is the significance of the mechanical life rating?


The mechanical life of 240 operations indicates the switch’s durability and reliability, ensuring it can withstand extensive use in demanding applications without failure.

How does the short hinge roller lever enhance performance?


The short hinge roller lever design provides precise actuation, enabling quick responses in applications where accurate movement is essential for operation.

What are the implications of using this component in high-temperature scenarios?


With an operational temperature range up to +80°C, it remains functional and reliable in challenging environments, helping to avoid equipment failures.
