Omron D4B Series Adjustable Roller Lever Limit Switch, 1 NO/1 NC, IP67, Metal Housing, 400V
- RS Stock No.:
- 214-7522
- Mfr. Part No.:
- D4B-4A17N
- Brand:
- Omron
Subtotal (1 unit)*
£63.07
(exc. VAT)
£75.68
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 13 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £63.07 |
*price indicative
- RS Stock No.:
- 214-7522
- Mfr. Part No.:
- D4B-4A17N
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Actuator Type | Adjustable Roller Lever | |
| Product Type | Limit Switch | |
| Contact Configuration | 1 NO/1 NC | |
| IP Rating | IP67 | |
| Housing Material | Metal | |
| Contact Type | Snap Action | |
| Terminal Type | Screw | |
| Series | D4B | |
| Switching AC Voltage | 400V | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | 80°C | |
| Width | 50mm | |
| Length | 72mm | |
| Standards/Approvals | UL, CSA, RoHS, CCC, CE | |
| Depth | 30mm | |
| Hazardous Area Certification | NO | |
| Conduit Entry | M20 | |
| Mechanical Life | 10000000Cycles | |
| Mounting Orientation | Multi Directional | |
| Operating Force | 2.12N | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Actuator Type Adjustable Roller Lever | ||
Product Type Limit Switch | ||
Contact Configuration 1 NO/1 NC | ||
IP Rating IP67 | ||
Housing Material Metal | ||
Contact Type Snap Action | ||
Terminal Type Screw | ||
Series D4B | ||
Switching AC Voltage 400V | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature 80°C | ||
Width 50mm | ||
Length 72mm | ||
Standards/Approvals UL, CSA, RoHS, CCC, CE | ||
Depth 30mm | ||
Hazardous Area Certification NO | ||
Conduit Entry M20 | ||
Mechanical Life 10000000Cycles | ||
Mounting Orientation Multi Directional | ||
Operating Force 2.12N | ||
The Omron safety limit switch has adjustable rod lever. It has slow action.
It has head seal structure to strengthened to improve seal properties
Safety of lever settings ensured
