Kingbright KPTD-2012LVSYCK
- RS Stock No.:
- 236-4455
- Mfr. Part No.:
- KPTD-2012LVSYCK
- Brand:
- Kingbright
Bulk discount available
Subtotal (1 reel of 3000 units)*
£453.00
(exc. VAT)
£543.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 - 3000 | £0.151 | £453.00 |
| 6000 - 12000 | £0.136 | £408.00 |
| 15000 + | £0.128 | £384.00 |
*price indicative
- RS Stock No.:
- 236-4455
- Mfr. Part No.:
- KPTD-2012LVSYCK
- Brand:
- Kingbright
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Kingbright | |
| Maximum Forward Current | 175mA | |
| Packaging | Tape & Reel | |
| Maximum Power Dissipation | 75mW | |
| LED Luminosity | 90 mcd | |
| Lens Dimensions | 0.65 x 0.8 mm | |
| Lens Shape | Round | |
| Select all | ||
|---|---|---|
Brand Kingbright | ||
Maximum Forward Current 175mA | ||
Packaging Tape & Reel | ||
Maximum Power Dissipation 75mW | ||
LED Luminosity 90 mcd | ||
Lens Dimensions 0.65 x 0.8 mm | ||
Lens Shape Round | ||
- COO (Country of Origin):
- CN
The Kingbright yellow SMD LED chip device is MADE with AlGaInP (on GaAs substrate) light emitting diode chip. Electrostatic discharge and power surge could damage the LED. It is recommended to use a wrist band or anti-electrostatic glove when handling the LED. All devices, equipment's and machineries must be electrically grounded.
2.0 mm x 1.25 mm SMD LED, 1.05 mm thickness
Low power consumption
Ideal for backlight and indicator
Package 3000 pcs / reel
Moisture sensitivity level 3
Halogen-free
RoHS compliant
