- RS Stock No.:
- 176-6195
- Mfr. Part No.:
- 156125GS57000
- Brand:
- Wurth Elektronik
275 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 25)
£0.297
(exc. VAT)
£0.356
(inc. VAT)
Units | Per unit | Per Pack* |
25 - 225 | £0.297 | £7.425 |
250 - 600 | £0.288 | £7.20 |
625 - 1225 | £0.279 | £6.975 |
1250 - 2475 | £0.27 | £6.75 |
2500 + | £0.262 | £6.55 |
*price indicative |
- RS Stock No.:
- 176-6195
- Mfr. Part No.:
- 156125GS57000
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
Characteristics
Small size & thin body for space saving
Ideal for narrow space applications
Wide viewing angle
Low power consumption
Industry standard footprint
Small package for exceptional brightness
Compatible with automatic placement machine
Diffused lens
Applications
Front panel indicators
LCD backlighting
Keypad backlighting
Push button backlighting
Symbol and switch backlighting
General lighting
Small size & thin body for space saving
Ideal for narrow space applications
Wide viewing angle
Low power consumption
Industry standard footprint
Small package for exceptional brightness
Compatible with automatic placement machine
Diffused lens
Applications
Front panel indicators
LCD backlighting
Keypad backlighting
Push button backlighting
Symbol and switch backlighting
General lighting
Specifications
Attribute | Value |
---|---|
LED Colours | Green |
Package Type | 1205 |
Mounting Type | Surface Mount |
Number of LEDs | 1 |
Forward Voltage | 3.9 V |
Luminous Intensity | 200 mcd |
Number of Pins | 2 |
Viewing Angle | 160 ° |
Lens Shape | Rectangle |
Dominant Wavelength | 525 nm |
Dimensions | 3.2 x 1.2 x 1.1mm |
Lens Finish | Diffused |
Series | WL-SMRD |
Lens Colour | Clear |
Forward Current | 20mA |
