2.5 V Red LED SMD, Lumileds LUXEON CZ L1CU-RED1000000000

  • RS Stock No. 173-6525
  • Mfr. Part No. L1CU-RED1000000000
  • Brand Lumileds
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): MY
Product Details

LUXEON CZ Color Line is an optically advanced portfolio of Color and White LEDs. Designed to maximize punch, the LUXEON CZ Color Line is the optimal LED solution for architecture, entertainment and emergency vehicle lighting applications.

Small and symmetrical 2x2mm² package
Industry leading Hot/Cold Factors and the lowest thermal resistance
Maximized punch (cd/lm)
Architectural & Entertainment
Lamps
Color Tunable
Specialty Lighting
Emergency Vehicle

Specifications
Attribute Value
LED Colours Red
Mounting Type Surface Mount
Number of LEDs 1
Forward Voltage 2.5 V
Number of Pins 2
Viewing Angle 120 °
Luminous Flux 31 lm
Lens Shape Square
Dominant Wavelength 634 nm
Dimensions 2 x 2 x 0.8mm
Forward Current 350mA
Series LUXEON CZ
Lens Colour Red
1645 In stock - FREE next working day delivery available
Price Each (In a Pack of 5)
£ 1.622
(exc. VAT)
£ 1.946
(inc. VAT)
Units
Per unit
Per Pack*
5 - 20
£1.622
£8.11
25 - 45
£1.07
£5.35
50 - 120
£1.024
£5.12
125 - 245
£0.93
£4.65
250 +
£0.83
£4.15
*price indicative
