RS PRO 2.4 V Red Panel Mount LED Indicator PLCC 2 Surface
- RS Stock No.:
- 280-107
- Brand:
- RS PRO
Bulk discount available
View bulk pricing optionsSubtotal (50 units, in packs of 50)*
£2.40
(exc. VAT)
£2.90
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 11,100 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 50 - 450 | £0.048 | £2.40 |
| 500 - 950 | £0.046 | £2.30 |
| 1000 - 2450 | £0.042 | £2.10 |
| 2500 - 4950 | £0.039 | £1.95 |
| 5000 + | £0.038 | £1.90 |
*price indicative
- RS Stock No.:
- 280-107
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | Panel Mount LED Indicator | |
| LED Colour | Red | |
| Package Type | PLCC 2 | |
| Maximum Forward Current | 25mA | |
| Mount Type | Surface | |
| Forward Voltage | 2.4V | |
| Maximum Power Dissipation | 60mW | |
| Number of Pins | 2 | |
| Viewing Angle | 120 ° | |
| Lens Dimensions | 1.6 x 0.8 mm | |
| Dominant Wavelength | 623nm | |
| Standards/Approvals | RoHS, REACH | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type Panel Mount LED Indicator | ||
LED Colour Red | ||
Package Type PLCC 2 | ||
Maximum Forward Current 25mA | ||
Mount Type Surface | ||
Forward Voltage 2.4V | ||
Maximum Power Dissipation 60mW | ||
Number of Pins 2 | ||
Viewing Angle 120 ° | ||
Lens Dimensions 1.6 x 0.8 mm | ||
Dominant Wavelength 623nm | ||
Standards/Approvals RoHS, REACH | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The RS Pro LED, measuring 1.6 x 0.8mm, offers high reliability and is RoHS & REACH compliant. It is ideal for applications such as flat backlighting for LCDs, switches and symbols, light pipe applications, and indicator and backlighting in office equipment.
Package in 8mm tape on 7inch diameter reel
Compatible with automatic placement equipment
Compatible with infrared and vapour phase reflow solder processes
Product remains within RoHS compliant version
