Inventronics IP20 2 Output LED Driver, 300V, 75 W, 700mA DALI LED Driver
- RS Stock No.:
- 212-2157
- Distrelec Article No.:
- 302-38-153
- Mfr. Part No.:
- OTI-DALI-75/220-240/700-D-NFC-TW-L
- Brand:
- Inventronics
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£55.75
(exc. VAT)
£66.90
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 15 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £55.75 |
| 5 - 9 | £53.52 |
| 10 - 24 | £51.40 |
| 25 - 49 | £49.34 |
| 50 + | £47.32 |
*price indicative
- RS Stock No.:
- 212-2157
- Distrelec Article No.:
- 302-38-153
- Mfr. Part No.:
- OTI-DALI-75/220-240/700-D-NFC-TW-L
- Brand:
- Inventronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Inventronics | |
| Output Voltage | 300V | |
| Product Type | LED Driver | |
| Maximum Output Power | 75W | |
| Input Voltage | 220, 240V | |
| Mount Type | Screw | |
| Sub Type | LED Driver | |
| Dimming Operation | DALI | |
| Terminal Type | Push-in | |
| Input Voltage Type | AC | |
| IP Rating | IP20 | |
| LED Voltage | 198, 264V ac | |
| Operating Modes | Constant Current | |
| Driver Current | 700mA | |
| Number of Outputs | 2 | |
| Series | OTI DALI | |
| Standards/Approvals | CCC, CE, EL, EN, ENEC, RCM, VDE-EMC | |
| Configuration | Enclosed | |
| Primary Type | AC-DC | |
| Power Dissipation | 6W | |
| Select all | ||
|---|---|---|
Brand Inventronics | ||
Output Voltage 300V | ||
Product Type LED Driver | ||
Maximum Output Power 75W | ||
Input Voltage 220, 240V | ||
Mount Type Screw | ||
Sub Type LED Driver | ||
Dimming Operation DALI | ||
Terminal Type Push-in | ||
Input Voltage Type AC | ||
IP Rating IP20 | ||
LED Voltage 198, 264V ac | ||
Operating Modes Constant Current | ||
Driver Current 700mA | ||
Number of Outputs 2 | ||
Series OTI DALI | ||
Standards/Approvals CCC, CE, EL, EN, ENEC, RCM, VDE-EMC | ||
Configuration Enclosed | ||
Primary Type AC-DC | ||
Power Dissipation 6W | ||
The Osram DALI (non-isolated) linear constant current LED driver with dimmable. Uses in linear lighting solutions for industry, storage areas and retail applications. Suitable for luminaires of protection class I.
Fully programmable via T4T software (NFC, DALI Interface) Wide operating temperature range: -40 to +65 °C High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE) Integrated inrush current limiter
