MEAN WELL LED Driver, 24V Output, 240 W Output, 10A 3 in 1 Dimming
- RS Stock No.:
- 424-810
- Mfr. Part No.:
- HLG-240H-24
- Brand:
- MEAN WELL
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£57.47
(exc. VAT)
£68.96
(inc. VAT)
- RS Stock No.:
- 424-810
- Mfr. Part No.:
- HLG-240H-24
- Brand:
- MEAN WELL
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Product Type | LED Driver | |
| Output Voltage | 24V | |
| Maximum Output Power | 240W | |
| Input Voltage | 127, 431V dc | |
| Mount Type | Screw | |
| Sub Type | LED Driver | |
| Dimming Operation | 3 in 1 Dimming | |
| Input Voltage Type | DC | |
| IP Rating | IP65, IP67 | |
| Driver Current | 10A | |
| LED Voltage | 12, 24V | |
| Operating Modes | Constant Current/Constant Voltage | |
| Standards/Approvals | UL8750, BIS IS15885( for 48V only), KC61347-1, CAN/CSA-C22.2 No. 107.1-01, GB19510.14(except for C-type), BS EN/ES/NZS 61347-2-13 independent (except for HLG-240H C type), J61347-2-13(except for B,AB and D-type), J61347-1, BS EN/ES/NZS 61347-1, CSA C22.2 No. 250.0-08, GB19510.1, KC61347-2-13(except for AB,C,D-type) Approved, IEC/UL/BS EN/EN 62368-1(except for AB,D type), UL1012, UL8750(type”HL”), IP65 or IP67, EAC TP TC 004 | |
| Series | HLG | |
| Number of Outputs | 1 | |
| Power Dissipation | 0.5W | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Product Type LED Driver | ||
Output Voltage 24V | ||
Maximum Output Power 240W | ||
Input Voltage 127, 431V dc | ||
Mount Type Screw | ||
Sub Type LED Driver | ||
Dimming Operation 3 in 1 Dimming | ||
Input Voltage Type DC | ||
IP Rating IP65, IP67 | ||
Driver Current 10A | ||
LED Voltage 12, 24V | ||
Operating Modes Constant Current/Constant Voltage | ||
Standards/Approvals UL8750, BIS IS15885( for 48V only), KC61347-1, CAN/CSA-C22.2 No. 107.1-01, GB19510.14(except for C-type), BS EN/ES/NZS 61347-2-13 independent (except for HLG-240H C type), J61347-2-13(except for B,AB and D-type), J61347-1, BS EN/ES/NZS 61347-1, CSA C22.2 No. 250.0-08, GB19510.1, KC61347-2-13(except for AB,C,D-type) Approved, IEC/UL/BS EN/EN 62368-1(except for AB,D type), UL1012, UL8750(type”HL”), IP65 or IP67, EAC TP TC 004 | ||
Series HLG | ||
Number of Outputs 1 | ||
Power Dissipation 0.5W | ||
RoHS Status: Exempt
