MEAN WELL LED Driver, 36V Output, 320W Output, 8.9A Output, Constant Current / Constant Voltage Dimmable
- RS Stock No.:
- 149-541
- Mfr. Part No.:
- HLG-320H-36AB
- Brand:
- MEAN WELL
Subtotal (1 unit)*
£72.15
(exc. VAT)
£86.58
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 8 unit(s) shipping from 22 December 2025
- Plus 9 unit(s) shipping from 23 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £72.15 |
*price indicative
- RS Stock No.:
- 149-541
- Mfr. Part No.:
- HLG-320H-36AB
- Brand:
- MEAN WELL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | MEAN WELL | |
Output Voltage | 36V | |
Maximum Output Power | 320W | |
Output Current | 8.9A | |
Dimmable | Yes | |
Input Voltage | 90 to 305 V | |
Operation | Constant Current / Constant Voltage | |
LED Driver Type | LED Driver | |
Select all | ||
---|---|---|
Brand MEAN WELL | ||
Output Voltage 36V | ||
Maximum Output Power 320W | ||
Output Current 8.9A | ||
Dimmable Yes | ||
Input Voltage 90 to 305 V | ||
Operation Constant Current / Constant Voltage | ||
LED Driver Type LED Driver | ||
RoHS Status: Exempt
The MEANWELL AC-DC Single output LED Driver is a versatile and high-quality power supply solution. With a mix mode of Constant Voltage (CV) and Constant Current (CC) with Power Factor Correction (PFC), it offers an output of 36Vdc at 8.9A. The driver is IP65 rated and offers dimming options with 1-10Vdc 10V PWM resistance. It is designed for adjustable current output through a built-in potentiometer, providing flexibility and efficiency for LED applications.
Mix mode of Constant Voltage (CV) and Constant Current (CC) for flexible power output
High quality and reliable LED driver for long-lasting performance
IP65 rated for outdoor and rugged industrial applications
Dimming capabilities with 1-10Vdc 10V PWM resistance for customizable lighting scenarios
Adjustable output current through built-in potentiometer for easy customization
High quality and reliable LED driver for long-lasting performance
IP65 rated for outdoor and rugged industrial applications
Dimming capabilities with 1-10Vdc 10V PWM resistance for customizable lighting scenarios
Adjustable output current through built-in potentiometer for easy customization
