Wurth 330 μH ±10% Ferrite Leaded Inductor, Max SRF:2MHz, 1.2A Idc, 370mΩ Rdc, WE-TIF
- RS Stock No.:
- 163-7916
- Mfr. Part No.:
- 7447211331
- Brand:
- Wurth Elektronik
Subtotal (1 tray of 80 units)*
£90.72
(exc. VAT)
£108.88
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 13 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tray* |
---|---|---|
80 + | £1.134 | £90.72 |
*price indicative
- RS Stock No.:
- 163-7916
- Mfr. Part No.:
- 7447211331
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Wurth Elektronik | |
Inductance | 330 μH | |
Maximum DC Current | 1.2A | |
Mounting Type | Radial | |
Maximum DC Resistance | 370mΩ | |
Tolerance | ±10% | |
Diameter | 11mm | |
Length | 11mm | |
Depth | 11mm | |
Height | 15mm | |
Dimensions | 11 (Dia.) x 15mm | |
Core Material | Ferrite | |
Maximum Self Resonant Frequency | 2MHz | |
Lead Pitch | 4 x 5mm | |
Series | WE-TIF | |
Lead Diameter | 0.8mm | |
Terminal Type | Radial Leaded | |
Minimum Operating Temperature | -40°C | |
Maximum Operating Temperature | +125°C | |
Select all | ||
---|---|---|
Brand Wurth Elektronik | ||
Inductance 330 μH | ||
Maximum DC Current 1.2A | ||
Mounting Type Radial | ||
Maximum DC Resistance 370mΩ | ||
Tolerance ±10% | ||
Diameter 11mm | ||
Length 11mm | ||
Depth 11mm | ||
Height 15mm | ||
Dimensions 11 (Dia.) x 15mm | ||
Core Material Ferrite | ||
Maximum Self Resonant Frequency 2MHz | ||
Lead Pitch 4 x 5mm | ||
Series WE-TIF | ||
Lead Diameter 0.8mm | ||
Terminal Type Radial Leaded | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +125°C | ||
- COO (Country of Origin):
- CN
Wurth WE-TIF Series Radial Leaded Wirewound Inductors
WE-TIF wire wound inductors from Wurth Elektronik are constructed from a high saturation core material and feature a maximum current up to 3.1 A. WE-TIF wire wound inductors have four pins. The use of two extra pins ensures higher mechanical stability than standard two-pin designs
Product Application Information
These wire wound inductors are suitable for use in DC-DC converters, EMI and power supply filters and signal filtering. Other suitable applications include switching power, LED power supplies, small and medium voltage supplies and nearfield applications.
Wurth Leaded Inductors (Chokes)
