binder Circular Connector, 4 Contacts, Cable, M16 Connector, Plug, Female, IP67, 723 Series
- RS Stock No.:
- 261-6017
- Mfr. Part No.:
- 09-0110-25-04
- Brand:
- binder
Subtotal (1 unit)*
£23.80
(exc. VAT)
£28.56
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 21 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £23.80 |
*price indicative
- RS Stock No.:
- 261-6017
- Mfr. Part No.:
- 09-0110-25-04
- Brand:
- binder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | binder | |
| Product Type | Circular Connector | |
| Number of Contacts | 4 | |
| Mount Type | Cable | |
| Current | 6A | |
| Connector Size | M16 | |
| Plug/Socket | Plug | |
| Contact Gender | Female | |
| IP Rating | IP67 | |
| Series | 723 | |
| Orientation | Straight | |
| Voltage | 250V | |
| Termination Type | Solder | |
| Mating Type | Screw-On | |
| Minimum Operating Temperature | -30°C | |
| Shell Size | 21.5 mm | |
| Maximum Operating Temperature | 95°C | |
| Housing Material | Nylon | |
| Standards/Approvals | No | |
| Pole Format | 4 | |
| Contact Plating | Silver | |
| Contact Material | Bronze | |
| Select all | ||
|---|---|---|
Brand binder | ||
Product Type Circular Connector | ||
Number of Contacts 4 | ||
Mount Type Cable | ||
Current 6A | ||
Connector Size M16 | ||
Plug/Socket Plug | ||
Contact Gender Female | ||
IP Rating IP67 | ||
Series 723 | ||
Orientation Straight | ||
Voltage 250V | ||
Termination Type Solder | ||
Mating Type Screw-On | ||
Minimum Operating Temperature -30°C | ||
Shell Size 21.5 mm | ||
Maximum Operating Temperature 95°C | ||
Housing Material Nylon | ||
Standards/Approvals No | ||
Pole Format 4 | ||
Contact Plating Silver | ||
Contact Material Bronze | ||
- COO (Country of Origin):
- DE
Cable Sockets
From Binder, this Series 723 miniature cable mount socket is screw-locking for secure and reliable mating attenuation. Easy to assemble and featuring internal strain relief, this connector has a robust metal construction. When mated, Series 723 connections are sealed to IP67 which means complete protection from contact dust and excellent protection against water.
Binder 723 Series
Binder 723 series plugs and sockets feature brass nut screw-coupling mechanism and plastic insert with solder termination. The screw coupling mechanism incorporates a gasket, sealing the cable mount connectors to IP67 when mated and locked together in-line, or with the relevant chassis mounted connectors.
