TE Connectivity Circular Connector, 9 Contacts, Panel Mount, Socket, Male, CPC Series 1 Series

View this category

Subtotal (1 bag of 100 units)*

£354.30

(exc. VAT)

£425.20

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 400 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Bag*
100 +£3.543£354.30

*price indicative

RS Stock No.:
164-8866
Mfr. Part No.:
182922-1
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Number of Contacts

9

Mounting Type

Panel Mount

Connector Size

Standard

Plug/Socket

Socket

Contact Gender

Male

Body Orientation

Straight

Series

CPC Series 1

COO (Country of Origin):
IT

TE Connectivity Series 1 CPC Connectors, Standard Sex Receptacles


Series 1 standard sex CPC circular plastic connectors with threaded couplings and black thermoplastic housings with keying for accurate alignment and square flanges for panel mounting. The square flanges of these standard sex CPC connectors have 4 x mounting holes or threaded inserts (see stock number 719-9302).
Series 1 circular plastic connectors with stock numbers 718-2749, 718-2752 and 745-5729 are PCB through hole mount.
Series 1 circular plastic connectors with stock numbers 680-6860 and 709-9767 are VDE tested.

TE Connectivity Circular Power Connector


The TE Connectivity CPC series 1 9-contact, the male circular power connector has a socket type connection. This panel mount connector has a voltage rating of 600VAC. The threaded connectors mate with cable mount plugs and receptacles provide endless connection possibilities. This connector is constructed from a thermoplastic material to provide a convenient and reliable connection system suited to a wide range of industrial applications. Crimp contacts can be removed if damaged, supporting rapid repair and eliminating valuable downtime.

Features and Benefits


Straight body orientation
Solder termination method
Unshielded
Waterproof
Shell size is 23mm
Quick connect/disconnect capability with thread assist, positive detent coupling
Built-in pin and socket protection
Polarized for proper mating of connector halves
Removable contacts and replaceable coupling ring make field repair easy
Operation temperature ranging between -40°C and 80°C

Applications


Agricultural equipment
Automotive (bus, truck, etc.)
HVAC
Industrial automation
Industrial machinery
Instrumentation
Lighting
Process control

Certifications


IP67 rated
UL approved


TE Connectivity CPC Plastic Series 1, 2 and 3
