JST 6-Way IDC Connector Socket for Cable Mount, 1-Row
- RS Stock No.:
- 311-6467
- Mfr. Part No.:
- 06HR-6S-P-N
- Brand:
- JST
910 In stock - FREE next working day delivery available
Added
Price Each (In a Pack of 10)
£0.445
(exc. VAT)
£0.534
(inc. VAT)
| Units | Per unit | Per Pack* |
| 10 - 240 | £0.445 | £4.45 |
| 250 - 740 | £0.392 | £3.92 |
| 750 - 1990 | £0.382 | £3.82 |
| 2000 + | £0.373 | £3.73 |
| *price indicative | ||
- RS Stock No.:
- 311-6467
- Mfr. Part No.:
- 06HR-6S-P-N
- Brand:
- JST
Technical Reference
Legislation and Compliance
Product Details
EH Series IDC Socket Housing
Ultra-thin
Accepts 26awg wire
Metal strain relief for vibration resistance
Crimp tool stock no. 311-6495
Accepts 26awg wire
Metal strain relief for vibration resistance
Crimp tool stock no. 311-6495
Approvals
UL File No. 60389, CSA File No. LR20812
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 6 |
| Number of Rows | 1 |
| Gender | Female |
| Pitch | 2.5mm |
| Mounting Type | Cable Mount |
| Body Orientation | Straight |
| Termination Method | IDC |
| Current Rating | 2A |
| Contact Plating | Tin Lead Alloy over Copper |
| Series | HR |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +85°C |
| Voltage Rating | 250 V dc, 250 V ac |
| Contact Material | Phosphor Bronze |
| Housing Material | Nylon |
- RS Stock No.:
- 311-6467
- Mfr. Part No.:
- 06HR-6S-P-N
- Brand:
- JST
