Omron 14-Way Connector Male for Through Hole, 1 Row
- RS Stock No.:
- 202-6924
- Mfr. Part No.:
- XG4A-1431
- Brand:
- Omron
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 202-6924
- Mfr. Part No.:
- XG4A-1431
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Number of Contacts | 14 | |
| Product Type | Connector | |
| Number of Rows | 1 | |
| Current | 3A | |
| Pitch | 22.86mm | |
| Connector Gender | Male | |
| Shrouded/Unshrouded | Shrouded | |
| Voltage | 250V | |
| Mount Type | Through Hole | |
| Orientation | Straight | |
| Contact Plating | Gold over Nickel | |
| Minimum Operating Temperature | -55°C | |
| Series | XG4A | |
| Termination Type | IDC | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | No | |
| Housing Material | Fibreglass Reinforced Polybutylene Terephthalate | |
| Contact Material | Brass Nickel | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Number of Contacts 14 | ||
Product Type Connector | ||
Number of Rows 1 | ||
Current 3A | ||
Pitch 22.86mm | ||
Connector Gender Male | ||
Shrouded/Unshrouded Shrouded | ||
Voltage 250V | ||
Mount Type Through Hole | ||
Orientation Straight | ||
Contact Plating Gold over Nickel | ||
Minimum Operating Temperature -55°C | ||
Series XG4A | ||
Termination Type IDC | ||
Contact Gender Male | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals No | ||
Housing Material Fibreglass Reinforced Polybutylene Terephthalate | ||
Contact Material Brass Nickel | ||
- COO (Country of Origin):
- CN
The Omron XG4A series flat cable connector, is a mainstream of circuit board connector that comes with new improved design. There are various plugs which are available like space-saving box-type plugs, IDC plugs which can be used for relaying. These connectors comes with long locks and straight DIP terminals.
Improves reliability
Conforms to MIL standards
RoHS compliant
