Parker Steel In Line Mount Mounting, Hydraulic Check Valve, 2303, G, 50L/min, 0.35 bar Cracking Pressure
- RS Stock No.:
- 237-2470
- Mfr. Part No.:
- 2303
- Brand:
- Parker
Subtotal (1 unit)*
£66.11
(exc. VAT)
£79.33
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 5 unit(s) ready to ship
- Plus 1 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £66.11 |
*price indicative
- RS Stock No.:
- 237-2470
- Mfr. Part No.:
- 2303
- Brand:
- Parker
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Parker | |
| Product Type | Hydraulic Check Valve | |
| Cracking Pressure | 0.35bar | |
| Connection Thread Standard | G | |
| Body Material | Steel | |
| Maximum Flow Rate | 50L/min | |
| Series | FDHB500UK | |
| Maximum Operating Pressure | 350 bar | |
| Maximum Operating Temperature | 90°C | |
| Minimum Operating Temperature | -30°C | |
| Mount Type | In Line Mount | |
| Width | 9.5mm | |
| Height | 74mm | |
| Length | 74mm | |
| Standards/Approvals | No | |
| Thread Size | 1/2 in | |
| Select all | ||
|---|---|---|
Brand Parker | ||
Product Type Hydraulic Check Valve | ||
Cracking Pressure 0.35bar | ||
Connection Thread Standard G | ||
Body Material Steel | ||
Maximum Flow Rate 50L/min | ||
Series FDHB500UK | ||
Maximum Operating Pressure 350 bar | ||
Maximum Operating Temperature 90°C | ||
Minimum Operating Temperature -30°C | ||
Mount Type In Line Mount | ||
Width 9.5mm | ||
Height 74mm | ||
Length 74mm | ||
Standards/Approvals No | ||
Thread Size 1/2 in | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
Steel Check Valves
Designed to allow flow in one direction and shut-off in the reverse direction.
Nylon seals
Note
Not suitable for use with water.
