RS PRO Brown 6mm² Hook Up Wire, 16 AWG, 75/0.3 mm, 100m, PVC Insulation
- RS Stock No.:
- 902-8442
- Brand:
- RS PRO
Subtotal (1 reel of 100 metres)*
£162.38
(exc. VAT)
£194.86
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
- Plus 30 unit(s) shipping from 18 December 2025
- Plus 30 unit(s) shipping from 12 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £162.38 | £1.624 |
*price indicative
- RS Stock No.:
- 902-8442
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Cross Sectional Area | 6mm² | |
| Sheath Colour | Brown | |
| Cable Shape | Round | |
| American Wire Gauge | 16 AWG | |
| Core Strands | 75/0.3 mm | |
| Length | 100m | |
| European Harmonised Code | H07V-K | |
| Insulation Material | PVC | |
| Voltage Rating | 750 V | |
| Outer Diameter | 5.3mm | |
| CPR Certification | Eca | |
| Maximum Operating Temperature | +70°C | |
| Current Rating | 54A | |
| Conductor Material | Copper | |
| Standards Met | IEC 60332-1 | |
| Fire Behaviour | Flame Retardant | |
| Series | H07V-K | |
| Harmonised Code | H07V-K | |
| Size of Strands | 0.3mm | |
| Outer Sheath Material | PVC | |
| Number of Strands | 75 | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Cross Sectional Area 6mm² | ||
Sheath Colour Brown | ||
Cable Shape Round | ||
American Wire Gauge 16 AWG | ||
Core Strands 75/0.3 mm | ||
Length 100m | ||
European Harmonised Code H07V-K | ||
Insulation Material PVC | ||
Voltage Rating 750 V | ||
Outer Diameter 5.3mm | ||
CPR Certification Eca | ||
Maximum Operating Temperature +70°C | ||
Current Rating 54A | ||
Conductor Material Copper | ||
Standards Met IEC 60332-1 | ||
Fire Behaviour Flame Retardant | ||
Series H07V-K | ||
Harmonised Code H07V-K | ||
Size of Strands 0.3mm | ||
Outer Sheath Material PVC | ||
Number of Strands 75 | ||
- COO (Country of Origin):
- TR
RS PRO 1-Core 6 mm² H07V-K Power Cable, Brown PVC Sheath 100 m, 750 V
Looking for a flexible cable that you can use for low-voltage applications? Turn to this power cable from RS PRO. Its sheath is made of PVC (polyvinyl chloride) to insulate the electric current for safety. The durable PVC material is also flame-retardant and resistant to chemicals and abrasion, so it's perfect for demanding industrial applications.
The cable is supplied on a 100 m reel, so you have plenty of wire to work with. It's suitable to install in environments such as workplaces and homes, as it meets the H07V-K harmonised code. You'll commonly find it used in plugs, circuit boards, household appliances and other small electronic devices.
The cable is supplied on a 100 m reel, so you have plenty of wire to work with. It's suitable to install in environments such as workplaces and homes, as it meets the H07V-K harmonised code. You'll commonly find it used in plugs, circuit boards, household appliances and other small electronic devices.
Features and Benefits
- Copper conductor material
- Conductor resistance of 3.3 Ω/km
- Stranded conductor type
- Core strand diameter of 0.3 mm
- Cross-sectional area of 6 mm²
- Flame-retardant
- H07V-K harmonised code
- Length of 100 m
- Single core
- 75 strands
- Outer diameter of 5.3 mm
- Brown sheath colour
- Polyvinyl chloride (PVC) sheath material
- Meets IEC 60332-1 fire safety standards for electric cables
- Voltage rating of 750 V
