RS PRO 0.75 mm² Harsh Environment Wire, 18 AWG, 24/0.2 mm, 25m, Silicone Rubber Insulation
- RS Stock No.:
- 776-1998
- Brand:
- RS PRO
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Alternative
This product is not currently available. Here is our alternative recommendation.
1 Reel of 100 Metre(s)
£59.96
(exc. VAT)
£71.95
(inc. VAT)
- RS Stock No.:
- 776-1998
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Cross Sectional Area | 0.75 mm² | |
| American Wire Gauge | 18 AWG | |
| Cable Shape | Single Core | |
| Core Strands | 24/0.2 mm | |
| Length | 25m | |
| Insulation Material | Silicone Rubber | |
| Outer Diameter | 2.5mm | |
| Voltage Rating | 300 → 500 V | |
| Maximum Operating Temperature | +200°C | |
| Minimum Operating Temperature | -60°C | |
| Conductor Material | Annealed Copper | |
| Standards Met | VDE | |
| Shield Type | Glass Braid | |
| Size of Strands | 0.2 mm | |
| Resistant To | Flame | |
| Number of Strands | 24 | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Cross Sectional Area 0.75 mm² | ||
American Wire Gauge 18 AWG | ||
Cable Shape Single Core | ||
Core Strands 24/0.2 mm | ||
Length 25m | ||
Insulation Material Silicone Rubber | ||
Outer Diameter 2.5mm | ||
Voltage Rating 300 → 500 V | ||
Maximum Operating Temperature +200°C | ||
Minimum Operating Temperature -60°C | ||
Conductor Material Annealed Copper | ||
Standards Met VDE | ||
Shield Type Glass Braid | ||
Size of Strands 0.2 mm | ||
Resistant To Flame | ||
Number of Strands 24 | ||
RS PRO Harsh Environment Wire 0.75 mm² CSA, 25 m Reel
Need to wire up equipment for use in tough conditions? This harsh environment wire from RS PRO is designed for use in situations where high temperatures or fluid spillages could threaten the integrity of electronic installations, creating safety risks.
The cable's annealed copper conductors combine flexibility with excellent conductivity, so you can be sure of a strong connection. They're insulated with silicone rubber and sheathed in polyurethane (PU)-impregnated fibreglass braiding, helping the cable operate at temperatures anywhere between -60°C and +200°C. The cable will even operate at up to +250°C for a short period of time.
The wire conforms to the ECD 73/23/EEC low-voltage directive and VDE standards, so it's certified as a safe and effective cable for use at voltages below 1000 V AC or 1500 DC. Cables of this kind are commonly found being used in construction sites, or installed in aeroplanes and car engines.
The cable's annealed copper conductors combine flexibility with excellent conductivity, so you can be sure of a strong connection. They're insulated with silicone rubber and sheathed in polyurethane (PU)-impregnated fibreglass braiding, helping the cable operate at temperatures anywhere between -60°C and +200°C. The cable will even operate at up to +250°C for a short period of time.
The wire conforms to the ECD 73/23/EEC low-voltage directive and VDE standards, so it's certified as a safe and effective cable for use at voltages below 1000 V AC or 1500 DC. Cables of this kind are commonly found being used in construction sites, or installed in aeroplanes and car engines.
Features and Benefits
• Wire size of 18 American Wire Gauge (AWG)
• Single-core
• Cross-sectional area of 0.75 mm²
• Silicone-rubber insulation material
• Glass braid shield type
• Annealed copper conductor material
• Flame-resistant
• Length of 25 m
• Outer diameter of 2.5 mm
• 24 core strands of 0.2 mm
• Strand size of 0.2 mm
• Voltage rating of 300 to 500 V
• Minimum operating temperature of -60°C
• Maximum operating temperature of +200°C
• Verband der Elektrotechnik (VDE) compliant
• Single-core
• Cross-sectional area of 0.75 mm²
• Silicone-rubber insulation material
• Glass braid shield type
• Annealed copper conductor material
• Flame-resistant
• Length of 25 m
• Outer diameter of 2.5 mm
• 24 core strands of 0.2 mm
• Strand size of 0.2 mm
• Voltage rating of 300 to 500 V
• Minimum operating temperature of -60°C
• Maximum operating temperature of +200°C
• Verband der Elektrotechnik (VDE) compliant
