Alpha Wire Ecogen Ecowire Plus Series Yellow Hook Up Wire, 12 AWG 19 x, 25 AWG core strands, 100 ft, Modified
- RS Stock No.:
- 277-8210
- Distrelec Article No.:
- 301-38-440
- Mfr. Part No.:
- 6830 YL005
- Brand:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
£243.79
(exc. VAT)
£292.55
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 08 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £243.79 | £8.126 |
*price indicative
- RS Stock No.:
- 277-8210
- Distrelec Article No.:
- 301-38-440
- Mfr. Part No.:
- 6830 YL005
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Product Type | Hook Up Wire | |
| Jacket Colour | Yellow | |
| American Wire Gauge | 12AWG | |
| Core Strands | 19 x 25AWG | |
| Cable Length | 100ft | |
| Outside Diameter | 3.05mm | |
| Voltage | 300V | |
| Maximum Operating Temperature | 110°C | |
| Conductor Material | Copper | |
| Standards/Approvals | EC 1907/2006, EU Directive 2015/863/EU, Low Voltage Directive 2014/35/EU, EU RoHS II 2011/65/EU | |
| Jacket Material | Modified Polyphenylene Ether | |
| Cable Type | Single Core | |
| Minimum Operating Temperature | -40°C | |
| Fire Behaviour | Halogen Free | |
| Series | Ecogen Ecowire Plus | |
| Number of Strands | 19 | |
| Size of Strands | 25AWG | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Product Type Hook Up Wire | ||
Jacket Colour Yellow | ||
American Wire Gauge 12AWG | ||
Core Strands 19 x 25AWG | ||
Cable Length 100ft | ||
Outside Diameter 3.05mm | ||
Voltage 300V | ||
Maximum Operating Temperature 110°C | ||
Conductor Material Copper | ||
Standards/Approvals EC 1907/2006, EU Directive 2015/863/EU, Low Voltage Directive 2014/35/EU, EU RoHS II 2011/65/EU | ||
Jacket Material Modified Polyphenylene Ether | ||
Cable Type Single Core | ||
Minimum Operating Temperature -40°C | ||
Fire Behaviour Halogen Free | ||
Series Ecogen Ecowire Plus | ||
Number of Strands 19 | ||
Size of Strands 25AWG | ||
RoHS Status: Exempt
The Alpha Wire hook up wire is up to 45 percent smaller diameter and up to 40 percent lighter fully recyclable wire. Ecowire plus offers all the environmental benefits of our standard ecowire, plus the additional fluid resistance for demanding factory applications. Ecowire plus derives its advantage from its unique insulation, a modified polyphenylene ether thermoplastic. Its mPPE-based insulation is non-halogenated and contains no heavy metal pigments, allowing it to help manufacturers meet waste electrical and electronic equipment requirements.
RoHS and REACH compliant
It provides better dielectric strength and wide temperature range
