Alpha Wire Hook-up Wire TEFLON Series Green 0.08 mm² Hook Up Wire, 28 AWG, 7/0.13 mm, 305m, PTFE Insulation, 5852 GR001
- RS Stock No.:
- 277-3709
- Distrelec Article No.:
- 301-17-180
- Mfr. Part No.:
- 5852 GR001
- Brand:
- Alpha Wire
Subtotal (1 reel of 305 metres)*
£259.95
(exc. VAT)
£311.94
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 4 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £259.95 | £0.852 |
*price indicative
- RS Stock No.:
- 277-3709
- Distrelec Article No.:
- 301-17-180
- Mfr. Part No.:
- 5852 GR001
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 0.08 mm² | |
| Sheath Colour | Green | |
| Cable Shape | Wire/Single Core | |
| American Wire Gauge | 28 AWG | |
| Core Strands | 7/0.13 mm | |
| Length | 305m | |
| Insulation Material | PTFE | |
| Series | Hook-up Wire TEFLON | |
Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 0.08 mm² | ||
Sheath Colour Green | ||
Cable Shape Wire/Single Core | ||
American Wire Gauge 28 AWG | ||
Core Strands 7/0.13 mm | ||
Length 305m | ||
Insulation Material PTFE | ||
Series Hook-up Wire TEFLON | ||
RoHS Status: Exempt
The Alpha Wire Hook up wire from Alpha means you will find the product exactly suited to your application. whether its as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high temperature oven, or off road construction equipment.
Resistance to chemicals
High electrical performance
Resistance to oil and solvents
Ability to withstand wear and abrasion
Bend radius is 10 times the cable diameter
High electrical performance
Resistance to oil and solvents
Ability to withstand wear and abrasion
Bend radius is 10 times the cable diameter
