RS PRO RS PRO Series Black 0.33 mm² Hook Up Wire, 22 AWG, 7, 100 m, Polyvinyl Chloride

RS Stock No.:: 207-5285
Brand:: RS PRO

RS PRO RS PRO Series Black 0.33 mm² Hook Up Wire, 22 AWG, 7, 100 m, Polyvinyl Chloride

Subtotal (1 reel of 100 metres)*

£26.80

(exc. VAT)

£32.20

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

3,300 unit(s) ready to ship
Plus 800 unit(s) ready to ship from another location
Plus 3,200 unit(s) shipping from 26 June 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Reel*
100 +	£0.268	£26.80

*price indicative

RS PRO Cable Ties

From electrical to industrial applications, RS Pro offers a wide selection of cable ties to suit every need. Durable, reliable, and available in multiple sizes and materials, trusted by professionals across industries.

Shop here

RS Stock No.:: 207-5285
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Product Type	Hook Up Wire
	Cross Sectional Area	0.33 mm²
	Jacket Colour	Black
	American Wire Gauge	22AWG
	Core Strands	7
	Cable Length	100m
	Outside Diameter	2.4 mm
	Voltage	600 V
	Maximum Operating Temperature	105°C
	Conductor Material	Tinned Copper
	Minimum Operating Temperature	-5°C
	Jacket Material	Polyvinyl Chloride
	Cable Type	Single Core
	Standards/Approvals	RoHS
	Fire Behaviour	Flame Retardant
	Series	RS PRO

	Select all
	Brand RS PRO
	Product Type Hook Up Wire
	Cross Sectional Area 0.33 mm²
	Jacket Colour Black
	American Wire Gauge 22AWG
	Core Strands 7
	Cable Length 100m
	Outside Diameter 2.4 mm
	Voltage 600 V
	Maximum Operating Temperature 105°C
	Conductor Material Tinned Copper
	Minimum Operating Temperature -5°C
	Jacket Material Polyvinyl Chloride
	Cable Type Single Core
	Standards/Approvals RoHS
	Fire Behaviour Flame Retardant
	Series RS PRO

COO (Country of Origin):: CN

RS PRO Hook Up Wire - UL1015

Our RS PRO range of hook up wires keeps on improving. We are pleased to introduce a new series of UL 1015 flexible hook-up wire perfect for internal wiring and electrical equipment. These 22 AWG copper conductor wires are supplied on a reel with red, blue or black insulated sheaths, and offered in 100 metre lengths.

Upon inspection the cables are solid, extremely robust, core strands are tinned copper and have a voltage rating of 600 V. The equipment wires are protected with insulation made from high-quality PVC ensuring the cables are reliable and meet the criteria for installation.

What is a hook-up wire?

Hook up wire, or copper wire/equipment wire as it's also called is primarily used for low or high voltage applications. Copper strands are insulated and act as the conductor of electricity to power its target.

What is hook up wire used for?

These type of hook-up wires are frequently found within the everyday household and workplace appliances. If a device has multiple wires to operate, hook up wire will usually be installed with different sheath colours on their respective terminals.

Features and Benefits

• Voltage rating 600 V

• Rated Temperature -5°C to +105°C

• Core Strands: 7/0.25 mm

• Tinned copper conductor wire - 22 AWG (American Wire Gauge)

• Cross Sectional Area: 0.33 mm²

• Insulation: Black PVC

• Fire Resistant, Flame Retardant

• Supplied on 100 m reel

• UL & CSA Approved

RS PRO UL1015 Hook Up Wires Options – 22 AWG

• 100 Metre Reel, Black, RS stock no: 207-5285

• 100 Metre Reel, Red, RS stock no: 207-5287

Applications

Hook up wire can be used for a broad range of appliances that include;

• Electrical Equipment

• Electronics

• Motors & Transformers

Why would you choose RS PRO for Hook Up Wires?

Our extensive range ensures we have your ideal solution available. Browsing our offer has vastly improved making it simple to select your hook up wire of choice. Our products are supported with technical information and customer service we are sure you will appreciate.
