Alpha Wire 3057 Series Green, White Hook Up Wire, 16 AWG, 26, 1000 ft, 3057 WG001
- RS Stock No.:
- 291-558
- Mfr. Part No.:
- 3057 WG001
- Brand:
- Alpha Wire
Subtotal (1 reel of 305 metres)*
£223.17
(exc. VAT)
£267.80
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 20 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £223.17 | £0.732 |
*price indicative
- RS Stock No.:
- 291-558
- Mfr. Part No.:
- 3057 WG001
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Product Type | Hook Up Wire | |
| Jacket Colour | Green, White | |
| American Wire Gauge | 16AWG | |
| Core Strands | 26 | |
| Cable Length | 1000ft | |
| Maximum Operating Temperature | 105°C | |
| Conductor Material | Tinned Copper | |
| Minimum Operating Temperature | -40°C | |
| Standards/Approvals | CE: EU Low Voltage Directive 2014/35/EU, California Proposition 65, CSA International TR-64 90C FT1, UL AWM/STYLE 1007 80C / 300 VRMS AWM/STYLE 1569 105C / 300 VRMS VW-1, REACH Regulation (EC 1907/2006), IEC EN 60332-1 Flame Behavior, EU Directive 2015/863/EU (RoHS3), EU Directive 2011/65/EU(RoHS2) | |
| Cable Type | Hookup | |
| Fire Behaviour | Flame Retardant | |
| Series | 3057 | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Product Type Hook Up Wire | ||
Jacket Colour Green, White | ||
American Wire Gauge 16AWG | ||
Core Strands 26 | ||
Cable Length 1000ft | ||
Maximum Operating Temperature 105°C | ||
Conductor Material Tinned Copper | ||
Minimum Operating Temperature -40°C | ||
Standards/Approvals CE: EU Low Voltage Directive 2014/35/EU, California Proposition 65, CSA International TR-64 90C FT1, UL AWM/STYLE 1007 80C / 300 VRMS AWM/STYLE 1569 105C / 300 VRMS VW-1, REACH Regulation (EC 1907/2006), IEC EN 60332-1 Flame Behavior, EU Directive 2015/863/EU (RoHS3), EU Directive 2011/65/EU(RoHS2) | ||
Cable Type Hookup | ||
Fire Behaviour Flame Retardant | ||
Series 3057 | ||
Non Compliant
Rupali
The Alpha Wire Hook Up Wire supports a bend radius of 10 times the cable diameter and a maximum pull tension of 20.4 lbs. Its electrical properties include a 300 VRMS voltage rating. This broad range of hook up wire ensures you will find the perfect solution for your application, whether its as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high temperature oven or off road construction equipment. These wires are designed to meet your requirements for temperature resistance, durability against wear and abrasion and reliable electrical performance.
RoHS compliance
Resistance to oil and solvents
Resistance to chemicals
