Alpha Wire 3055 Series Grey/White 0.81 mm² Hook Up Wire, 18 AWG, 16/30, 100ft, PVC Insulation, 3055 WS005
- RS Stock No.:
- 291-362
- Mfr. Part No.:
- 3055 WS005
- Brand:
- Alpha Wire
Bulk discount available
Subtotal (1 reel of 30 metres)*
£33.04
(exc. VAT)
£39.65
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 - 3 | £33.04 | £1.101 |
| 4 + | £30.40 | £1.013 |
*price indicative
- RS Stock No.:
- 291-362
- Mfr. Part No.:
- 3055 WS005
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 0.81 mm² | |
| Sheath Colour | Grey/White | |
| Cable Shape | Round | |
| American Wire Gauge | 18 AWG | |
| Core Strands | 16/30 | |
| Length | 100ft | |
| Insulation Material | PVC | |
| Series | 3055 | |
Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 0.81 mm² | ||
Sheath Colour Grey/White | ||
Cable Shape Round | ||
American Wire Gauge 18 AWG | ||
Core Strands 16/30 | ||
Length 100ft | ||
Insulation Material PVC | ||
Series 3055 | ||
Rupali
The Alpha Wire Hook Up Wire supports a bend radius of 10 times the cable diameter and a maximum pull tension of 12.6 lbs. Its electrical properties include a 300 VRMS voltage rating. This broad range of hook up wire ensures you will find the perfect solution for your application, whether its as straightforward as a control cabinet in a protected environment or as specialized as a machine tool on the factory floor, a high temperature oven or off road construction equipment. These wires are designed to meet your requirements for temperature resistance, durability against wear and abrasion and reliable electrical performance.
RoHS compliance
Resistance to oil and solvents
Resistance to chemicals
Resistance to oil and solvents
Resistance to chemicals
