Alpha Wire 460619 Series Red 13.32 mm² Hook Up Wire, 6 AWG, 19/.0372, 100ft, PVC Insulation, 460619 RD005
- RS Stock No.:
- 290-640
- Mfr. Part No.:
- 460619 RD005
- Brand:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
£248.70
(exc. VAT)
£298.44
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 09 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £248.70 | £8.29 |
*price indicative
- RS Stock No.:
- 290-640
- Mfr. Part No.:
- 460619 RD005
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 13.32 mm² | |
| Sheath Colour | Red | |
| Cable Shape | Round | |
| American Wire Gauge | 6 AWG | |
| Core Strands | 19/.0372 | |
| Length | 100ft | |
| Insulation Material | PVC | |
| Series | 460619 | |
Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 13.32 mm² | ||
Sheath Colour Red | ||
Cable Shape Round | ||
American Wire Gauge 6 AWG | ||
Core Strands 19/.0372 | ||
Length 100ft | ||
Insulation Material PVC | ||
Series 460619 | ||
- COO (Country of Origin):
- US
Gavin
The Alpha Wire Hook Up Wire is versatile and can be used in a variety of environments, from simple control cabinets in protected areas to more specialized applications such as machine tools on the factory floor, high-temperature ovens, or off-road construction equipment. They are designed to operate within a temperature range of -40°C to 105°C, making them suitable for both standard and challenging conditions. It has a bend radius more than 10 times of the cable diameter.
RoHS compliant
Bare copper conductor
PVC insulation
Resistant to oil and solvents
Resistant to chemicals
Bare copper conductor
PVC insulation
Resistant to oil and solvents
Resistant to chemicals
