Alpha Wire 541626 Series White 1.32 mm² Hook Up Wire, 16 AWG, 26, 100 ft, Polyvinyl Chloride, 541626 WH005
- RS Stock No.:
- 289-864
- Mfr. Part No.:
- 541626 WH005
- Brand:
- Alpha Wire
Bulk discount available
Subtotal (1 reel of 30 metres)*
£33.50
(exc. VAT)
£40.20
(inc. VAT)
Stock information currently inaccessible - Please check back later
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 - 3 | £33.50 | £1.117 |
| 4 + | £30.82 | £1.027 |
*price indicative
- RS Stock No.:
- 289-864
- Mfr. Part No.:
- 541626 WH005
- Brand:
- Alpha Wire
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Alpha Wire | |
| Cross Sectional Area | 1.32 mm² | |
| Product Type | Hook Up Wire | |
| Jacket Colour | White | |
| American Wire Gauge | 16AWG | |
| Core Strands | 26 | |
| Cable Length | 100ft | |
| Voltage | 600 V | |
| Maximum Operating Temperature | 90°C | |
| Conductor Material | Copper | |
| Jacket Material | Polyvinyl Chloride | |
| Standards/Approvals | EU Directive 2015/863/EU (RoHS3), UL, REACH Regulation (EC 1907/2006), Directive 2011/65/EU(RoHS2), California Proposition 65 | |
| Minimum Operating Temperature | -40°C | |
| Cable Type | Hookup | |
| Series | 541626 | |
| Select all | ||
|---|---|---|
Brand Alpha Wire | ||
Cross Sectional Area 1.32 mm² | ||
Product Type Hook Up Wire | ||
Jacket Colour White | ||
American Wire Gauge 16AWG | ||
Core Strands 26 | ||
Cable Length 100ft | ||
Voltage 600 V | ||
Maximum Operating Temperature 90°C | ||
Conductor Material Copper | ||
Jacket Material Polyvinyl Chloride | ||
Standards/Approvals EU Directive 2015/863/EU (RoHS3), UL, REACH Regulation (EC 1907/2006), Directive 2011/65/EU(RoHS2), California Proposition 65 | ||
Minimum Operating Temperature -40°C | ||
Cable Type Hookup | ||
Series 541626 | ||
Non Compliant
- COO (Country of Origin):
- CA
Gavin
The Alpha Wire Hook Up Wire is versatile and can be used in a variety of environments, from simple control cabinets in protected areas to more specialized applications such as machine tools on the factory floor, high-temperature ovens, or off-road construction equipment. They are designed to operate within a temperature range of -40°C to 90°C, making them suitable for both standard and challenging conditions. It has a bend radius more than 10 times of the cable diameter.
RoHS compliant
Bare copper conductor
Resistant to oil and solvents
Resistant to chemicals
