HARTING Heavy Duty Power Connector Insert, 10A, Male, Han-Modular Series, 8 Contacts

Han MegaBit insert suitable for ethernet Cat.5e, offered in male and female versions.These ethernet modules are suitable for Han B, Han M, Han EMC and Han HPR hoods/housings, 360 degree shielding and with a data rate of 100 Mbits per second, crimp contacts need to ordered separately.

Number of contacts 2x4
Operating temperature range -40 to +125°C
Over 500 mating cycles
Rated at 10A, 50V

DIN EN 60 664-1, DIN EN 61 984

This heavy duty power connector insert is part of a robust connection solution designed for demanding applications. This male connector insert features a crimp termination method and accommodates up to eight contacts. It supports a current rating of 10A and a voltage rating of 50V, making it suitable for various industrial environments. The connector is cable mount type with a straight body orientation, ensuring ease of installation in tight spaces.

• Compatible with Han-Modular connectors to provide flexible configurations
• 10A current handling capability ensures reliable power distribution
• Crimp termination connectors improve mechanical stability and electrical performance
• Eight contact points allow for efficient multi-connection setups
• Straight body orientation enhances installation simplicity
• Designed for cable mounting, facilitating versatile applications

• Utilised for automation machinery requiring reliable power connections
• Effective in control panels for durable and secure interfacing
• Used in industrial machinery for effective power distribution
• Suitable for electronic equipment where robust connector solutions are necessary

Crimp termination methods enhance electrical contact reliability by providing a firm mechanical connection. This reduces the risk of loosening during operation and ensures optimal electrical conductivity in demanding conditions.

The 10A current rating allows for substantial power transfer, ensuring the connector can handle the demands of industrial applications without overheating or compromising performance.

This connector is designed for industrial settings such as factories, workshops, and assembly lines, where heavy duty and dependable connections are vital for efficient operations.

Having eight contacts enables the connection of multiple circuits within a single connector, streamlining wiring tasks and optimising space in constrained environments.

Harting Han® Modular

The Han-Modular series is a system consisting of insert modules and frames into which the insert modules fit. These in turn may be fitted to standard Han® housings. The system allows a variety of insert configurations within the one connector assembly. The Han-Modular system is designed to meet specific requirements of individual customers and offers flexibility when considering connections for signal, power & pneumatic lines when a solution is required with one connector Apart from the quality of the crimp connector, the right choice of the assembly tool is the basic element of a reliable connection. HARTING offers appropriate crimping tools for different levels of automation for all connectors.
