Molex Heavy Duty Power Connector Module, 16A, Male, 93601 Series, 10 Contacts
- RS Stock No.:
- 250-1939
- Mfr. Part No.:
- 936010230
- Brand:
- Molex
Bulk discount available
Subtotal (1 unit)*
£9.18
(exc. VAT)
£11.02
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 33 unit(s) shipping from 20 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £9.18 |
| 10 - 99 | £8.89 |
| 100 - 249 | £8.52 |
| 250 - 499 | £8.15 |
| 500 + | £7.72 |
*price indicative
- RS Stock No.:
- 250-1939
- Mfr. Part No.:
- 936010230
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Current Rating | 16A | |
| Gender | Male | |
| Series | 93601 | |
| Type | Push-in Terminal Insert | |
| For Use With | Electronic Machinery | |
| Number of Contacts | 10 | |
| Contact Material | Copper Alloy | |
| Contact Plating | Silver | |
Select all | ||
|---|---|---|
Brand Molex | ||
Current Rating 16A | ||
Gender Male | ||
Series 93601 | ||
Type Push-in Terminal Insert | ||
For Use With Electronic Machinery | ||
Number of Contacts 10 | ||
Contact Material Copper Alloy | ||
Contact Plating Silver | ||
- COO (Country of Origin):
- CN
Molex 93601 Series Heavy Duty Power Connector Module, 16A Current Rating, 10 Contact Power Connector - 936010230
This heavy duty power connector module is tailored for industrial applications. It features a compact 10-pin design, allowing for robust connections in electronic machinery. A male configuration enables seamless integration with compatible components, making it suitable for demanding environments.
Features & Benefits
• Current rating of 16A supports heavy load applications
• Voltage rating of 500V ensures high electrical reliability
• Silver-plated contacts enhance conductivity and durability
• Constructed with copper alloy for superior performance
• Push-in terminal insert simplifies installation and maintenance
• Operates within a temperature range of -40°C to +125°C
• Voltage rating of 500V ensures high electrical reliability
• Silver-plated contacts enhance conductivity and durability
• Constructed with copper alloy for superior performance
• Push-in terminal insert simplifies installation and maintenance
• Operates within a temperature range of -40°C to +125°C
Applications
• Ideal for use with electronic machinery connectors
• Suited for automation and control systems
• Works effectively in electrical and mechanical industries
• Compatible with size 10B hoods and housings
• Suited for automation and control systems
• Works effectively in electrical and mechanical industries
• Compatible with size 10B hoods and housings
What is the maximum wire size accommodated by this connector?
The connector supports a maximum wire size of 2.5mm², suitable for varying wire gauges, ensuring compatibility with a wide range of applications.
How many mating cycles can this connector endure?
This module is designed for a durability of up to 500 mating cycles, making it ideal for frequent use in robust industrial settings.
What materials are used in the construction of the contacts?
The contacts are made from copper alloy with silver plating, which optimises electrical performance and protects against corrosion.
What is the stripping length required for proper installation?
A stripping length of 9.00-11.00mm is required for effective terminal connections, ensuring a secure and reliable fit.
