Hammond 1594 Series Grey Flame Retardant ABS Enclosure, IP54, Grey Lid, 131.5 x 66.3 x 43mm

RS Stock No.:: 528-7016
Mfr. Part No.:: 1594DGY
Brand:: Hammond

Hammond 1594 Series Grey Flame Retardant ABS Enclosure, IP54, Grey Lid, 131.5 x 66.3 x 43mm

Sorry, we couldn't check our stock levels right now. Please try refreshing the page.

Not available for guaranteed pre 9am/10am delivery

Price Each

£8.88

(exc. VAT)

£10.66

(inc. VAT)

Units	Per unit
1 - 4	£8.88
5 - 9	£8.45
10 - 24	£7.99
25 - 49	£7.54
50 +	£7.12

RS Stock No.:: 528-7016
Mfr. Part No.:: 1594DGY
Brand:: Hammond

Heavy Duty ABS Enclosures 1594 Series - Flame Retardant

Hammond Series 1594 Enclosures are heavy duty, thick wall type enclosures that guarantee fire resistance and IP rating up to IP54. Enclosures are moulded from high-quality ABS plastic and feature screw mounting type lid. Perfect for applications with repetitive assembly and disassembly required.

Features and Benefits:

• Rugged electronic instrument enclosures, ideally suited for mounting printed circuit boards.

• Heavy duty, thick wall design with an average wall thickness of .13” (3.3 mm).

• Flame retardant ABS plastic (carries a UL flammability rating of 94V-0).

• Perfect for applications with repetitive assembly and disassembly required.

• Molded in general purpose ABS plastic.

• IP54 rated

FAQ:

What does IP rating mean?

The IP rating is used to define levels of sealing effectiveness of electrical enclosures against intrusion from foreign bodies (tools, dirt etc) and moisture. For more information please, visit SOLUTIONS section at the top of the page or click on Selection Guide of an Enclosures.

What is supplied?

• An enclosure with a lid

• Set of 4 lid mounting screws

Hammond Series 1594 Enclosure, Flame Retardant ABS Body, IP54 Rating - 1594DGY

This Hammond enclosure is a high-quality grey ABS enclosure with an IP54 rating, manufactured by Hammond. It is designed for a wide range of applications, providing durability and protection for electronics and other components.

Features & Benefits

• Flame retardant ABS material ensures safety and reliability
• Compact design with external dimensions of 131.5 x 66.3 x 55.1 mm
• IP54 rating for protection against dust and water
• Lightweight at 138g for easy handling

Applications

• Can be used to house circuit boards, components, and other sensitive equipment
• Can be used for protecting electronics in various environments

Can it be used outdoors?

Yes, the Hammond enclosure is suitable for outdoor use with its IP54 rating.

Will it protect sensitive electronics?

Yes, the flame retardant ABS material provides excellent protection for electronics.

Is it lightweight?

Yes, the enclosure is lightweight at only 138g for easy handling.

Can it house circuit boards?

Yes, the enclosure is designed to house circuit boards and other components.

Is it part of a series?

Yes, the enclosure is part of the Hammond 1594 series.

Approvals

Material Flamability Rating: UL94-V0

RS Stock No.:: 528-7016
Mfr. Part No.:: 1594DGY
Brand:: Hammond

Heavy Duty ABS Enclosures 1594 Series - Flame Retardant

Features and Benefits:

• Rugged electronic instrument enclosures, ideally suited for mounting printed circuit boards.

• Heavy duty, thick wall design with an average wall thickness of .13” (3.3 mm).

• Flame retardant ABS plastic (carries a UL flammability rating of 94V-0).

• Perfect for applications with repetitive assembly and disassembly required.

• Molded in general purpose ABS plastic.

• IP54 rated

FAQ:

What does IP rating mean?

What is supplied?

• An enclosure with a lid

• Set of 4 lid mounting screws

Hammond Series 1594 Enclosure, Flame Retardant ABS Body, IP54 Rating - 1594DGY

Features & Benefits

Applications

• Can be used to house circuit boards, components, and other sensitive equipment
• Can be used for protecting electronics in various environments

Can it be used outdoors?

Yes, the Hammond enclosure is suitable for outdoor use with its IP54 rating.

Will it protect sensitive electronics?

Yes, the flame retardant ABS material provides excellent protection for electronics.

Is it lightweight?

Yes, the enclosure is lightweight at only 138g for easy handling.

Can it house circuit boards?

Yes, the enclosure is designed to house circuit boards and other components.

Is it part of a series?

Yes, the enclosure is part of the Hammond 1594 series.

Approvals

Material Flamability Rating: UL94-V0

Attribute	Value
Body Material	Flame Retardant ABS
External Length	131.5 mm
External Height	43 mm
External Width	66.3 mm
External Dimensions	131.5 x 66.3 x 43mm
IP Rating	IP54
Range	1594
Colour	Grey
Lid Colour	Grey
Flanged	No
Shielded	No
Series	1594
Transparent Door	No
Weight	138g
Explosion Proof	No
RAL Code	RAL 7035

Attribute	Value
Body Material	Flame Retardant ABS
External Length	131.5 mm
External Height	43 mm
External Width	66.3 mm
External Dimensions	131.5 x 66.3 x 43mm
IP Rating	IP54
Range	1594
Colour	Grey
Lid Colour	Grey
Flanged	No
Shielded	No
Series	1594
Transparent Door	No
Weight	138g
Explosion Proof	No
RAL Code	RAL 7035
