Infineon MOSFET Gate Driver 2, 1.9 A 8-Pin 20 V, SOIC

View all Gate Drivers

Subtotal (1 reel of 2500 units)*

£1,425.00

(exc. VAT)

£1,700.00

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 2,500 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Reel*
2500 +£0.57£1,425.00

*price indicative

RS Stock No.:
226-6203
Mfr. Part No.:
IRS2183STRPBF
Brand:
Infineon
Find similar products by selecting one or more attributes.
Select all

Brand

Infineon

Product Type

MOSFET

Output Current

1.9A

Pin Count

8

Package Type

SOIC

Fall Time

35ns

Driver Type

MOSFET

Number of Outputs

2

Rise Time

40ns

Minimum Supply Voltage

20V

Maximum Supply Voltage

20V

Number of Drivers

2

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

125°C

Series

IRS2183

Standards/Approvals

No

Length

5mm

Width

4 mm

Height

1.75mm

Mount Type

Surface

Automotive Standard

No

The Infineon IRS2183 are high voltage, high speed power MOSFET and IGBT drivers with dependent high-side and low-side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. The logic input is compatible with standard CMOS or LSTTL output, down to 3.3 V logic.

Floating channel designed for bootstrap operation

Fully operational to +600 V

Tolerant to negative transient voltage, dV/dt immune

Gate drive supply range from 10 V to 20 V

Undervoltage lockout for both channel
