Infineon 1ED3461MC12MXUMA1, 6 A, 6.5V 16-Pin, PG-DSO-16

View all Gate Drivers
Bulk discount available

Subtotal (1 pack of 2 units)*

£8.16

(exc. VAT)

£9.80

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 1,000 unit(s) ready to ship
  • Plus 999,998,998 unit(s) shipping from 29 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
2 - 8£4.08£8.16
10 - 18£3.51£7.02
20 - 48£3.265£6.53
50 - 98£3.065£6.13
100 +£2.815£5.63

*price indicative

Packaging Options:
RS Stock No.:
225-0541
Mfr. Part No.:
1ED3461MC12MXUMA1
Brand:
Infineon
Find similar products by selecting one or more attributes.
Select all

Brand

Infineon

Output Current

6 A

Supply Voltage

6.5V

Pin Count

16

Fall Time

30ns

Package Type

PG-DSO-16

The Infineon 1ED3461MU12M belongs to the EiceDRIVER Enhanced 1ED34xx family single-channel isolated gate driver with adjustable DESAT and soft-off. Its suitable for IGBTs, MOSFETs and SiC MOSFETs. The 1ED3431 offers high configurability with DESAT, and soft-off, through external resistor from input side.

40 V absolute maximum output supply voltage
±3 A, ±6 A, and ±9 A typical sinking and sourcing peak output current
Separate source and sink outputs for hard switching and with active Miller clamp, clamp driver
Adjustment pins for parameter configuration from input side
