Littelfuse 20A Panel Mount Fuse Holder for 3AB, 3AG Fuse, 1P, 32V ac/dc
- RS Stock No.:
- 878-1675
- Mfr. Part No.:
- 03440024H
- Brand:
- Littelfuse
Discontinued
- RS Stock No.:
- 878-1675
- Mfr. Part No.:
- 03440024H
- Brand:
- Littelfuse
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Littelfuse | |
| Fuse Size | 3AB, 3AG | |
| Current Rating | 20A | |
| Voltage Rating | 32V ac/dc | |
| Number of Poles | 1 | |
| Standards Met | cULus Listed | |
| Cap Style | Manual | |
| Compatible Fuse Diameter | 6.3mm | |
| Series | 344 | |
| Compatible Fuse Length | 32mm | |
| Terminal Type | Quick Connect | |
| Contact Material | Tin Plated Copper Alloy | |
| Select all | ||
|---|---|---|
Brand Littelfuse | ||
Fuse Size 3AB, 3AG | ||
Current Rating 20A | ||
Voltage Rating 32V ac/dc | ||
Number of Poles 1 | ||
Standards Met cULus Listed | ||
Cap Style Manual | ||
Compatible Fuse Diameter 6.3mm | ||
Series 344 | ||
Compatible Fuse Length 32mm | ||
Terminal Type Quick Connect | ||
Contact Material Tin Plated Copper Alloy | ||
- COO (Country of Origin):
- MX
Littelfuse 344 Series Indicating Fuseholders
The Littelfuse 344 series panel mount indicating fuseholders are a robust solution to a variety of application requirements.The 344 series of fuseholder are compatible with 3AG fuses and comes with neoprene washer, lock-washer and hex nut unassembled.
Panel Mounting
CATEGORIES OF PROTECTION AGAINST ELECTRIC SHOCK,PC1: No integral protection against electric shock. If required, designers must provide additional protection against electric shock on equipment.,PC2: With integral protection against electric shock. Fuse-holders shall have live parts inaccessible to IEC529 standard test finger, when fully assembled, without fuse carrier or fuse in place and when fuse carrier, with fuse is being inserted or withdrawn.,PC3: With integral protection against electric shock. Fuse-holders shall have live parts inaccessible to IEC529 1mm diameter rigid test wire when fully assembled, without fuse carrier or fuse in place and when fuse carrier, with fuse is being inserted or withdrawn.
