Littelfuse 15A Panel Mount 6.3 x 32mm Cartridge Fuse Block, 250V ac/dc
- RS Stock No.:
- 878-1498
- Mfr. Part No.:
- 356001
- Brand:
- Littelfuse
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 878-1498
- Mfr. Part No.:
- 356001
- Brand:
- Littelfuse
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Littelfuse | |
| Fuse Type | Cartridge | |
| Fuse Size | 6.3 x 32mm | |
| Number of Fuses | 1 | |
| Current Rating | 15A | |
| Voltage Rating | 250V ac/dc | |
| Mounting Style | Panel Mount | |
| Compatible Fuse Class | 3AG | |
| Clip Material | Brass | |
| Holder Terminal Type | Screw | |
| For Use With | 3AG Fuses | |
| Series | 356 | |
| Standards Met | CSA Certified LR7316, Lead (Pb) Free, RoHS Compliant, UL Listed E14721 | |
Select all | ||
|---|---|---|
Brand Littelfuse | ||
Fuse Type Cartridge | ||
Fuse Size 6.3 x 32mm | ||
Number of Fuses 1 | ||
Current Rating 15A | ||
Voltage Rating 250V ac/dc | ||
Mounting Style Panel Mount | ||
Compatible Fuse Class 3AG | ||
Clip Material Brass | ||
Holder Terminal Type Screw | ||
For Use With 3AG Fuses | ||
Series 356 | ||
Standards Met CSA Certified LR7316, Lead (Pb) Free, RoHS Compliant, UL Listed E14721 | ||
- COO (Country of Origin):
- MX
Littelfuse Fuseholders and Clips - 6.3x32mm
Littelfuse fuseholders and clips offer a comprehensive solution to a variety of application requirements.
Note
Caps supplied separately
Panel Mounting
CATEGORIES OF PROTECTION AGAINST ELECTRIC SHOCK,PC1: No integral protection against electric shock. If required, designers must provide additional protection against electric shock on equipment.,PC2: With integral protection against electric shock. Fuse-holders shall have live parts inaccessible to IEC529 standard test finger, when fully assembled, without fuse carrier or fuse in place and when fuse carrier, with fuse is being inserted or withdrawn.,PC3: With integral protection against electric shock. Fuse-holders shall have live parts inaccessible to IEC529 1mm diameter rigid test wire when fully assembled, without fuse carrier or fuse in place and when fuse carrier, with fuse is being inserted or withdrawn.
