BK Precision 4007B Function Generator, 0.1Hz Min, 7MHz Max, Variable Sweep - RS Calibration

View all Function Generators
Discontinued
RS Stock No.:
122-2079
Mfr. Part No.:
BK4007B
Brand:
BK Precision
Find similar products by selecting one or more attributes.
Select all

Brand

BK Precision

Model Number

4007B

Calibrated

RSCAL

Digital Frequency

Yes

Minimum Frequency Range Sinewave

0.1Hz

Maximum Frequency Range Sinewave

7MHz

Maximum Frequency Range Square Pulse and Arbitrary Waveform

7MHz

Minimum Frequency Range Square Pulse and Arbitrary Waveform

0.1 Hz

Minimum Frequency Range Triangle/Saw

0.1Hz

Maximum Frequency Range Triangle/Saw

1MHz

Digital Amplitude and Offset

Yes

Internal Linear and Log Sweep

Yes

Variable Sweep

Yes

Weight

2kg

Maximum Operating Temperature

+50°C

Output Amplitude

20V Pk-Pk

Length

213mm

Dimensions

213 x 210 x 88mm

Minimum Operating Temperature

0°C

Height

88mm

Width

210mm

Output Impedance

50Ω

Frequency Range Square Pulse and Arbitrary Waveform

0.1 Hz → 7 MHz

RoHS Status: Not Applicable

COO (Country of Origin):
IL

B&K Precision Model 4007B DDS Function Generator


B&K Precision model BK4007B is a versatile sweep function generator using an advanced direct digital synthesis (DDS) design. The instrument generates sine, square and triangle waveforms with high signal precision and stability. It provides variable output voltages from 0 to 10 Vpp into 50 ohms or up to 20 Vpp into open circuit. A continuously variable DC offset allows the output to be injected directly into circuits at the correct bias level. An auxiliary TTL output at the generator’s frequency is available to synchronise external devices. Up to 9 front panel settings can be saved to memory storage.

Features and Benefits


Sine, square, and triangle/ramp waveform generation
Linear and logarithmic sweep
Adjustable duty cycle
Adjustable DC offset
Store and recall up to 9 instrument settings
Output On/Off button
Overvoltage, overcurrent and short circuit protection on main output

Areas of Application


Education
Other applications that need basic DDS function generators with sweep capability

Note

You may also be interested in model BK4013B ( 121-7543 ), 0.1 Hz - 12 MHz

Supplied with

Manual on CD, power cord, certificate of calibration
