Hirose, 52 0.8 mm Pitch 1 Way Straight Male FPC Connector, Crimp
- RS Stock No.:
- 162-0956
- Mfr. Part No.:
- DF52-2832PF1571-28A9-300
- Brand:
- Hirose
Bulk discount available
Subtotal (1 unit)*
£4.25
(exc. VAT)
£5.10
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 4 unit(s) ready to ship from another location
- Plus 60 unit(s) shipping from 12 March 2026
- Plus 400 unit(s) shipping from 03 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £4.25 |
| 10 - 24 | £3.90 |
| 25 - 49 | £3.55 |
| 50 - 99 | £3.32 |
| 100 + | £2.82 |
*price indicative
- RS Stock No.:
- 162-0956
- Mfr. Part No.:
- DF52-2832PF1571-28A9-300
- Brand:
- Hirose
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Hirose | |
| Product Type | FPC Connector | |
| Number of Contacts | 1 | |
| Sub Type | FPC | |
| Contact Material | Copper Alloy | |
| Current | 3A | |
| Pitch | 0.8mm | |
| Mount Type | Cable | |
| Connector Gender | Male | |
| Contact Position | Opposite Side | |
| Termination Type | Crimp | |
| Orientation | Straight | |
| Insertion Force | Non-ZIF | |
| Locking Mechanism | No | |
| Voltage | 100 V ac/dc | |
| Series | 52 | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 85°C | |
| Contact Gender | Male | |
| Number of Rows | 1 | |
| Standards/Approvals | No | |
| Contact Plating | Tin | |
| Housing Material | Copper | |
| Select all | ||
|---|---|---|
Brand Hirose | ||
Product Type FPC Connector | ||
Number of Contacts 1 | ||
Sub Type FPC | ||
Contact Material Copper Alloy | ||
Current 3A | ||
Pitch 0.8mm | ||
Mount Type Cable | ||
Connector Gender Male | ||
Contact Position Opposite Side | ||
Termination Type Crimp | ||
Orientation Straight | ||
Insertion Force Non-ZIF | ||
Locking Mechanism No | ||
Voltage 100 V ac/dc | ||
Series 52 | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 85°C | ||
Contact Gender Male | ||
Number of Rows 1 | ||
Standards/Approvals No | ||
Contact Plating Tin | ||
Housing Material Copper | ||
0.8 mm pitch, Small & Robust Wire to Board Connector
0.8 mm pitch, 1.75 mm height 4.1 mm depth small connector
Rated up to 2.5 Amps MAX with AWG#28, 2 pos.
Robust design is tolerant of cable wiring.
High contact lance strength
Box shape crimp contact prevents deformation
Supports cables with jacket O/D 0.5 to 0.6 mm, AWG#32 to 28
Halogen-free product
Plugs available in straight and receptacles available in right angle.
