Schneider Electric NSY Series Fibreglass Reinforced Polyester 1-Door Floor Standing Enclosure, Transparent Door, IP65
- RS Stock No.:
- 577-154
- Mfr. Part No.:
- NSYPLA574TG
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£1,475.02
(exc. VAT)
£1,770.02
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 01 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,475.02 |
*price indicative
- RS Stock No.:
- 577-154
- Mfr. Part No.:
- NSYPLA574TG
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Number of Doors | 1 | |
| Product Type | Floor Standing Enclosure | |
| IP Rating | IP65 | |
| Construction | Assembled Sealed | |
| Series | NSY | |
| Door Type | Transparent | |
| Body Material | Fibreglass Reinforced Polyester | |
| Colour | Grey | |
| External Width | 750mm | |
| External Depth | 420mm | |
| External Height | 500mm | |
| Colour RAL | RAL 7035 | |
| NEMA Rating | NEMA 3, NEMA 12, NEMA 2, NEMA 1, NEMA 5, NEMA 3S, NEMA 13, NEMA 3R, NEMA 3X | |
| Standards/Approvals | UL 508 A, IEC 62208 | |
| IK Rating | IK08 | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Number of Doors 1 | ||
Product Type Floor Standing Enclosure | ||
IP Rating IP65 | ||
Construction Assembled Sealed | ||
Series NSY | ||
Door Type Transparent | ||
Body Material Fibreglass Reinforced Polyester | ||
Colour Grey | ||
External Width 750mm | ||
External Depth 420mm | ||
External Height 500mm | ||
Colour RAL RAL 7035 | ||
NEMA Rating NEMA 3, NEMA 12, NEMA 2, NEMA 1, NEMA 5, NEMA 3S, NEMA 13, NEMA 3R, NEMA 3X | ||
Standards/Approvals UL 508 A, IEC 62208 | ||
IK Rating IK08 | ||
- COO (Country of Origin):
- ES
The Schneider Electric Multi purpose floor standing enclosure, version PLA, is a fully sealed polyester unit with IP65 protection and a glazed front, measuring 500x750x420 mm, it is composed of one top part, one bottom part, two side parts, one rear panel, and one door, making it a suitable enclosure for various applications requiring durability and environmental resistance.
IP65 conforming to IEC 60529
IK08 conforming to IEC 62262
