Alliance Memory NOR 128Mbit SPI Flash Memory 8-Pin WSON, AS25F1128MQ-70WIN

View all Flash Memory
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
665-367
Mfr. Part No.:
AS25F1128MQ-70WIN
Brand:
Alliance Memory
Find similar products by selecting one or more attributes.
Select all

Brand

Alliance Memory

Memory Size

128Mbit

Interface Type

SPI

Package Type

WSON

Pin Count

8

Organisation

128G x 8

Cell Type

NOR

COO (Country of Origin):
TW
The Alliance Memory 1.8V 128Mbit Serial Flash Memory with 4KB sectors supports Dual and Quad I/O SPI and QPI interfaces. It is compatible with the standard Serial Peripheral Interface (SPI) and Quad Peripheral Interface (QPI), utilizing Serial Clock, Chip Select, Serial Data I/O0 (DI), I/O1 (DO), I/O2 (WP), and I/O3 (HOLD). The device supports SPI clock frequencies up to 133MHz, enabling effective rates of 266MHz for Dual Output and 532MHz for Quad Output when using QPI and Fast Read Dual/Quad I/O instructions. The array is structured into 65,536 programmable pages of 256 bytes each, allowing up to 256 bytes to be programmed at a time via Page Program instructions. Erase operations can be performed by sector, 32KB block, 64KB block, or across the entire chip.

Software and Hardware Write protect Top or Bottom
Sector or Block selection Lock Down and OTP protection
Discoverable Parameters SFDP Register
Lead Free and Halogen Free
ROHS Compliant
