KEMET C87 Polypropylene Film Capacitor, 470V ac, ±5%, 3μF
- RS Stock No.:
- 911-9392
- Mfr. Part No.:
- C878BF34300SA4J
- Brand:
- KEMET
Bulk discount available
Subtotal (1 unit)*
£3.69
(exc. VAT)
£4.43
(inc. VAT)
FREE delivery for orders over £50.00
Being discontinued
- 52 left, ready to ship
- Plus 5 left, ready to ship from another location
Units | Per unit |
|---|---|
| 1 - 9 | £3.69 |
| 10 - 24 | £2.95 |
| 25 - 49 | £2.58 |
| 50 - 114 | £2.23 |
| 115 + | £2.03 |
*price indicative
- RS Stock No.:
- 911-9392
- Mfr. Part No.:
- C878BF34300SA4J
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Capacitance | 3µF | |
| Voltage | 470V ac | |
| Tolerance | ±5% | |
| Series | C87 | |
| Lead Pitch | 13.4mm | |
| Suppression Class | P2 | |
| Lead Length | 13mm | |
| Height | 48mm | |
| Dimensions | 30 (Dia.) x 48mm | |
| Dielectric | Polypropylene | |
| Terminal Type | FAST-ON (Double) | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +85°C | |
| Package/Case | SA | |
| Dissipation Factor | 20 x 10⁻⁴% | |
Select all | ||
|---|---|---|
Brand KEMET | ||
Capacitance 3µF | ||
Voltage 470V ac | ||
Tolerance ±5% | ||
Series C87 | ||
Lead Pitch 13.4mm | ||
Suppression Class P2 | ||
Lead Length 13mm | ||
Height 48mm | ||
Dimensions 30 (Dia.) x 48mm | ||
Dielectric Polypropylene | ||
Terminal Type FAST-ON (Double) | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature +85°C | ||
Package/Case SA | ||
Dissipation Factor 20 x 10⁻⁴% | ||
KEMET Motor Run Capacitors, C87 Series
C87 Series Polypropylene metallised film with cylindrical aluminium can type filled with resin; faston, plastic deck or cable terminals and overpressure safety device.
Features and Benefits:
High capacitance density
Self-healing metal layer
VDE, CQC and UL810 approved
Rated frequency of 50 Hz and 60 Hz
Safety device protection
High capacitance density
Self-healing metal layer
VDE, CQC and UL810 approved
Rated frequency of 50 Hz and 60 Hz
Safety device protection
Typical applications include Motor Run P2 safety class: Single phase motors, Low-power electric motors and compressors
Note
Alternative product available (see link)1810409 - Alternative Capacitor function & attributes will remain the same, except Nuts and washers will be packed in separate Plastic Bag in each box. This product will eventually replace this article.
