KEMET R75 Polypropylene Capacitor, 5 %, 150 nF 160 V dc 90V ac, Through Hole
- RS Stock No.:
- 212-6556
- Mfr. Part No.:
- R75GF315050H0J
- Brand:
- KEMET
Subtotal (1 pack of 5 units)*
£1.77
(exc. VAT)
£2.125
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 1,475 unit(s) shipping from 14 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | £0.354 | £1.77 |
*price indicative
- RS Stock No.:
- 212-6556
- Mfr. Part No.:
- R75GF315050H0J
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Product Type | Polypropylene Capacitor | |
| Capacitance | 150nF | |
| Mount Type | Through Hole | |
| Rated AC Voltage | 90V ac | |
| Tolerance | 5 % | |
| Packaging | Tape & Reel | |
| Series | R75 | |
| Rated DC Voltage | 160V dc | |
| Lead Pitch | 10mm | |
| Automotive Standard | AEC-Q200 | |
| Application | Resonant Circuit, Silicon Controlled Rectifier, High Frequency Medium to High Current | |
| Lead Length | 25mm | |
| Equivalent Series Resistance ESR | 10.6mΩ | |
| Minimum Operating Temperature | -55°C | |
| Pin Count | 2 | |
| Maximum Operating Temperature | 105°C | |
| Length | 13mm | |
| Height | 11mm | |
| Standards/Approvals | IEC 60286-2, RoHS | |
| Width | 5mm | |
| Dissipation Factor | 0.05% | |
| Package/Case | Plastic | |
| Lead Diameter | 0.6mm | |
| Select all | ||
|---|---|---|
Brand KEMET | ||
Product Type Polypropylene Capacitor | ||
Capacitance 150nF | ||
Mount Type Through Hole | ||
Rated AC Voltage 90V ac | ||
Tolerance 5 % | ||
Packaging Tape & Reel | ||
Series R75 | ||
Rated DC Voltage 160V dc | ||
Lead Pitch 10mm | ||
Automotive Standard AEC-Q200 | ||
Application Resonant Circuit, Silicon Controlled Rectifier, High Frequency Medium to High Current | ||
Lead Length 25mm | ||
Equivalent Series Resistance ESR 10.6mΩ | ||
Minimum Operating Temperature -55°C | ||
Pin Count 2 | ||
Maximum Operating Temperature 105°C | ||
Length 13mm | ||
Height 11mm | ||
Standards/Approvals IEC 60286-2, RoHS | ||
Width 5mm | ||
Dissipation Factor 0.05% | ||
Package/Case Plastic | ||
Lead Diameter 0.6mm | ||
- COO (Country of Origin):
- CN
The Kemet R75 series 0.15 uF metallized polypropylene film capacitor with radial leads of tinned wire. The capacitor is encapsulated in a self-extinguishing solvent resistant plastic case with thermosetting resin material.
RoHS compliant
Lead free terminations
Self healing
