KEMET R46 Polypropylene Film Capacitor, 310V ac, ±20%, 1μF, Through Hole
- RS Stock No.:
- 174-6332
- Mfr. Part No.:
- R463N410050N2M
- Brand:
- KEMET
Bulk discount available
Subtotal (1 pack of 10 units)*
£5.73
(exc. VAT)
£6.88
(inc. VAT)
Stock information currently inaccessible
Units | Per unit | Per Pack* |
---|---|---|
10 - 40 | £0.573 | £5.73 |
50 - 90 | £0.516 | £5.16 |
100 - 190 | £0.401 | £4.01 |
200 + | £0.38 | £3.80 |
*price indicative
- RS Stock No.:
- 174-6332
- Mfr. Part No.:
- R463N410050N2M
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | KEMET | |
Capacitance | 1µF | |
Voltage | 310V ac | |
Mounting Type | Through Hole | |
Tolerance | ±20% | |
Series | R46 | |
Lead Pitch | 22.5mm | |
Suppression Class | X1 | |
Length | 26.5mm | |
Depth | 10mm | |
Lead Length | 25mm | |
Height | 18.5mm | |
Dimensions | 26.5 x 10 x 18.5mm | |
Dielectric | Polypropylene | |
Terminal Type | Radial | |
Dissipation Factor | 0.1 % @ 1 kHz | |
Minimum Operating Temperature | -40°C | |
Lead Diameter | 0.8mm | |
Maximum Operating Temperature | +110°C | |
Select all | ||
---|---|---|
Brand KEMET | ||
Capacitance 1µF | ||
Voltage 310V ac | ||
Mounting Type Through Hole | ||
Tolerance ±20% | ||
Series R46 | ||
Lead Pitch 22.5mm | ||
Suppression Class X1 | ||
Length 26.5mm | ||
Depth 10mm | ||
Lead Length 25mm | ||
Height 18.5mm | ||
Dimensions 26.5 x 10 x 18.5mm | ||
Dielectric Polypropylene | ||
Terminal Type Radial | ||
Dissipation Factor 0.1 % @ 1 kHz | ||
Minimum Operating Temperature -40°C | ||
Lead Diameter 0.8mm | ||
Maximum Operating Temperature +110°C | ||
The R46 Series is constructed of metallized polypropylene film encapsulated with self-extinguishing resin.
Applications
For worldwide use in electromagnetic interference (EMI) suppression in across-the-line applications. Intended for use in situations where capacitor failure would not result in exposure to electric shock. Not for use in series with mains type applications.
Applications
For worldwide use in electromagnetic interference (EMI) suppression in across-the-line applications. Intended for use in situations where capacitor failure would not result in exposure to electric shock. Not for use in series with mains type applications.
Rated voltage: 310 VAC 50/60 Hz
Capacitance range: 0.01 – 10 μF
Lead spacing: 10.0 – 37.5 mm
Capacitance tolerance: ±20%, ±10%
Lead-free terminations
Operating temperature range of −40˚C to +110˚C
100% screening factory test at 2,200 VDC/1,500 VAC
Self-healing properties
Capacitance range: 0.01 – 10 μF
Lead spacing: 10.0 – 37.5 mm
Capacitance tolerance: ±20%, ±10%
Lead-free terminations
Operating temperature range of −40˚C to +110˚C
100% screening factory test at 2,200 VDC/1,500 VAC
Self-healing properties
