KEMET R82 Metallised Polyester Film Capacitor, 40 V ac, 63 V dc, ±5%, 220nF, Through Hole
- RS Stock No.:
- 174-6267
- Mfr. Part No.:
- R82DC3220Z360J
- Brand:
- KEMET
8000 In stock - FREE next working day delivery available
Added
Price Each (In a Bag of 4000)
£0.05
(exc. VAT)
£0.06
(inc. VAT)
| Units | Per unit | Per Bag* |
| 4000 - 8000 | £0.05 | £200.00 |
| 12000 + | £0.045 | £180.00 |
| *price indicative | ||
- RS Stock No.:
- 174-6267
- Mfr. Part No.:
- R82DC3220Z360J
- Brand:
- KEMET
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- ID
Product Details
The R82 Series is constructed of metallized polyester film (wound or stacked technology) with radial leads of tinned wire. Radial leads are electrically welded to the contact metal layer on the ends of the capacitor winding. The capacitor is encapsulated with thermosetting resin
Applications
Typical applications include blocking, coupling, decoupling, timing and oscillator circuits. Not suitable for across-the-line application (see Suppressor Capacitors).
Applications
Typical applications include blocking, coupling, decoupling, timing and oscillator circuits. Not suitable for across-the-line application (see Suppressor Capacitors).
Voltage range: 50 – 400 VDC
Capacitance range: 0.001 μF – 4.7 μF
Lead Spacing: 5 mm
Capacitance tolerance: ±5%, ±10%, ±20%
Climatic category: 55/105/56
Operating temperature range of -55˚C to +105˚C
Lead-free terminations
Tape and reel packaging
Self-healing
Capacitance range: 0.001 μF – 4.7 μF
Lead Spacing: 5 mm
Capacitance tolerance: ±5%, ±10%, ±20%
Climatic category: 55/105/56
Operating temperature range of -55˚C to +105˚C
Lead-free terminations
Tape and reel packaging
Self-healing
Specifications
Attribute | Value |
|---|---|
| Capacitance | 220nF |
| Voltage | 40 V ac, 63 V dc |
| Mounting Type | Through Hole |
| Tolerance | ±5% |
| Series | R82 |
| Automotive Standard | AEC-Q200 |
| Lead Pitch | 5mm |
| Length | 7.2mm |
| Depth | 2.5mm |
| Height | 6.5mm |
| Dimensions | 7.2 x 2.5 x 6.5mm |
| Dielectric | Metallised Polyester |
| Terminal Type | Radial |
| Lead Diameter | 0.5mm |
| Maximum Operating Temperature | +105°C |
| Dissipation Factor | 1.2 % @ 10 kHz |
| Minimum Operating Temperature | -55°C |
