KEMET C4BS Polypropylene Film Capacitor, 550 V ac, 850 V dc, ±5%, 5μF, Solder Lug
- RS Stock No.:
- 173-5121
- Mfr. Part No.:
- C4BSMBX4500ZBNJ
- Brand:
- KEMET
Bulk discount available
Subtotal (1 bag of 21 units)*
£307.272
(exc. VAT)
£368.718
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 105 unit(s) shipping from 08 October 2025
- Plus 105 unit(s) shipping from 30 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 21 - 21 | £14.632 | £307.27 |
| 42 + | £12.438 | £261.20 |
*price indicative
- RS Stock No.:
- 173-5121
- Mfr. Part No.:
- C4BSMBX4500ZBNJ
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Capacitance | 5µF | |
| Voltage | 550 V ac, 850 V dc | |
| Mounting Type | Solder Lug | |
| Tolerance | ±5% | |
| Series | C4BS | |
| Lead Pitch | 37mm | |
| Length | 57.5mm | |
| Lead Length | 17mm | |
| Depth | 35mm | |
| Height | 50mm | |
| Equivalent Series Resistance | 1.9mΩ | |
| Dimensions | 57.5 x 35 x 50mm | |
| Dielectric | Polypropylene | |
| Dissipation Factor | ≤5 x 10⁻⁴ % @1 kHz | |
| Package/Case | B | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
Select all | ||
|---|---|---|
Brand KEMET | ||
Capacitance 5µF | ||
Voltage 550 V ac, 850 V dc | ||
Mounting Type Solder Lug | ||
Tolerance ±5% | ||
Series C4BS | ||
Lead Pitch 37mm | ||
Length 57.5mm | ||
Lead Length 17mm | ||
Depth 35mm | ||
Height 50mm | ||
Equivalent Series Resistance 1.9mΩ | ||
Dimensions 57.5 x 35 x 50mm | ||
Dielectric Polypropylene | ||
Dissipation Factor ≤5 x 10⁻⁴ % @1 kHz | ||
Package/Case B | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
C4BS Series
KEMET C4BS Series polypropylene film capacitors – radial boxes are made from a metallised construction. These film capacitors are suitable for high frequency applications, they have high contact reliability and a high ripple current. The capacitors protect against large voltage transients at gate turn off, the C4BS series film capacitors are self-healing.
