KEMET C4AT Polypropylene Film Capacitor, 350 V ac, 600 V dc, ±5%, 20μF, Through Hole
- RS Stock No.:
- 173-1943
- Mfr. Part No.:
- C4ATHBW5200A3NJ
- Brand:
- KEMET
Bulk discount available
Subtotal (1 bag of 23 units)*
£226.55
(exc. VAT)
£271.86
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 69 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
---|---|---|
23 - 92 | £9.85 | £226.55 |
115 - 207 | £7.772 | £178.76 |
230 + | £7.378 | £169.69 |
*price indicative
- RS Stock No.:
- 173-1943
- Mfr. Part No.:
- C4ATHBW5200A3NJ
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | KEMET | |
Capacitance | 20µF | |
Voltage | 350 V ac, 600 V dc | |
Mounting Type | Through Hole | |
Tolerance | ±5% | |
Series | C4AT | |
Lead Pitch | 52.5mm | |
Length | 57.5mm | |
Depth | 35mm | |
Lead Length | 6mm | |
Equivalent Series Resistance | 3.2mΩ | |
Height | 50mm | |
Dimensions | 57.5 x 35 x 50mm | |
Dielectric | Polypropylene | |
Lead Diameter | 1.2mm | |
Package/Case | B | |
Minimum Operating Temperature | -40°C | |
Dissipation Factor | ≤5 x 10⁻⁴ % @1 kHz | |
Maximum Operating Temperature | +85°C | |
Select all | ||
---|---|---|
Brand KEMET | ||
Capacitance 20µF | ||
Voltage 350 V ac, 600 V dc | ||
Mounting Type Through Hole | ||
Tolerance ±5% | ||
Series C4AT | ||
Lead Pitch 52.5mm | ||
Length 57.5mm | ||
Depth 35mm | ||
Lead Length 6mm | ||
Equivalent Series Resistance 3.2mΩ | ||
Height 50mm | ||
Dimensions 57.5 x 35 x 50mm | ||
Dielectric Polypropylene | ||
Lead Diameter 1.2mm | ||
Package/Case B | ||
Minimum Operating Temperature -40°C | ||
Dissipation Factor ≤5 x 10⁻⁴ % @1 kHz | ||
Maximum Operating Temperature +85°C | ||
- COO (Country of Origin):
- IT
KEMET C4A MKP Series Capacitors
C4A MKP capacitors from KEMET are radial mount power capacitors with high ripple current and low losses. Encapsulated in a self-healing material, C4A power capacitors are ideal for high frequency applications.
Features and Benefits
Self-Healing
Low losses
High ripple current
High contact reliability
Low losses
High ripple current
High contact reliability
Standards
VDE 0560 - IEC61071 - EN61071
