KEMET R60 Metallised Polyester Film Capacitor, 63 V ac, 100 V dc, ±10%, 100μF, Through Hole
- RS Stock No.:
- 164-9749
- Mfr. Part No.:
- R60EW61005000K
- Brand:
- KEMET
Subtotal (1 bag of 252 units)*
£3,014.172
(exc. VAT)
£3,616.956
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 252 unit(s) shipping from 10 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
---|---|---|
252 + | £11.961 | £3,014.17 |
*price indicative
- RS Stock No.:
- 164-9749
- Mfr. Part No.:
- R60EW61005000K
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | KEMET | |
Capacitance | 100µF | |
Voltage | 63 V ac, 100 V dc | |
Mounting Type | Through Hole | |
Tolerance | ±10% | |
Series | R60 | |
Lead Pitch | 37.5mm | |
Automotive Standard | AEC-Q200 | |
Length | 41.5mm | |
Depth | 24mm | |
Height | 44mm | |
Dimensions | 41.5 x 24 x 44mm | |
Dielectric | Metallised Polyester | |
Terminal Type | Through Hole | |
Dissipation Factor | 1% | |
Minimum Operating Temperature | -55°C | |
Maximum Operating Temperature | +105°C | |
Lead Diameter | 1mm | |
Select all | ||
---|---|---|
Brand KEMET | ||
Capacitance 100µF | ||
Voltage 63 V ac, 100 V dc | ||
Mounting Type Through Hole | ||
Tolerance ±10% | ||
Series R60 | ||
Lead Pitch 37.5mm | ||
Automotive Standard AEC-Q200 | ||
Length 41.5mm | ||
Depth 24mm | ||
Height 44mm | ||
Dimensions 41.5 x 24 x 44mm | ||
Dielectric Metallised Polyester | ||
Terminal Type Through Hole | ||
Dissipation Factor 1% | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature +105°C | ||
Lead Diameter 1mm | ||
- COO (Country of Origin):
- MK
The R60 Series is constructed of metallized polyester film (wound or stacked technology) with radial leads of tinned wire. Radial leads are electrically welded to the contact metal layer on the ends of the capacitor winding. The capacitor is encapsulated with thermosetting resin in a box material.
Voltage range: 50 – 1000 VDC
Capacitance range: 0.001 μF – 150.0 μF
Lead spacing: 10.0 – 37.5 mm
Capacitance tolerance: ±5%, ±10%, ±20%
Climatic category: 55/105/56
Operating temperature range of −55°C to +105°C
Lead-free terminations
Tape and reel packaging–2
Self-healing
Automotive gradess up to pitch 22.5 mm
Capacitance range: 0.001 μF – 150.0 μF
Lead spacing: 10.0 – 37.5 mm
Capacitance tolerance: ±5%, ±10%, ±20%
Climatic category: 55/105/56
Operating temperature range of −55°C to +105°C
Lead-free terminations
Tape and reel packaging–2
Self-healing
Automotive gradess up to pitch 22.5 mm
